13
EDP_ LCDPWR (4-pin): EDP LCD Panel VCC 3.3V/5V/12V
(2.0 pitch)
1
3
5
4
6
2
6
4
2
5
3
1
6
4
2
5
3
1
EDP_LCDPWR
→
EDP LCD Panel VCC
2-4 Closed:
EDP LCD
VCC =3V;
3-4 Closed:
EDP LCD
VCC =5V;
4-6 Closed:
EDP LCD
VCC =12V;
