Intel H110 User Manual

38
Data Bits
The default setting is: [8].
*This item may or may not show up, depending on different configuration.
Parity
The default setting is: [None].
*This item may or may not show up, depending on different configuration.
Stop Bits
The default setting is: [1].
*This item may or may not show up, depending on different configuration.
 Network Stack Configuration
Press [Enter] to go to ‘Network Stack’ screen to make further settings.
Network Stack
Use this item to enable or disable UEFI Network Stack.
The optional settings: [Disabled]; [Enabled].
When set as [Enabled], the following sub-items shall appear:
IPv4 PXE Support
Use this item to enable IPv4 PXE Boot Support. When set as [Disabled], IPv4 PXE
boot option will not be created.
The optional settings: [Disabled]; [Enabled].
IPv4 HTTP Support
Use this item to enable IPv4 HTTP Boot Support. When set as [Disabled], IPv4
HTTP boot option will not be created.
The optional settings: [Disabled]; [Enabled].
Ipv6 PXE Support
Use this item to enable IPv6 PXE Boot Support. When set as [Disabled], IPv6 PXE
boot option will not be created.
The optional settings: [Disabled]; [Enabled].
Ipv6 HTTP Support
Use this item to enable IPv6 PXE Boot Support. When set as [Disabled], IPv6
HTTP boot option will not be created.
The optional settings: [Disabled]; [Enabled].
PXE boot wait time
Use this item to set wait time to press [ESC] key to abort the PXE boot.

Intel H110 Specifications

General

Socket	LGA 1151
Memory Type	DDR4
Max Memory	32 GB
Memory Slots	2
PCIe 3.0 x16 Slots	1
PCI Express Lanes	6
RAID Support	No
Chipset	Intel H110
SATA Ports	4
Form Factor	ATX, Micro-ATX, Mini-ITX
Memory Speed	2133 MHz
USB 3.0 Ports	4
USB 2.0 Ports	6
Memory Channels	2
