Intel H61 User Manual

6
Connectors
Connector Name
ATXPWR1 ATX Power Connector
ATX12V1 ATX 12V Power Connector
SATA1 NLB75: SATAIII Connector
NLH61 & NLH61-6C: SATAII Connector
SATA2/3/4 SATAII Connector X3
VGA Video Graphic Attach Connector
DVI DVI-D Port Connector
COM1 Serial Port COM Connector
COM3 Serial Port COM Connector
UL1(Top)/UL2(Top) RJ-45 LAN Connector X2
UL1(Middle & Bottom)
/UL2(Middle & Bottom)
USB 2.0 Port Connector X4
AUDIO Line Out /Line In /MIC
Audio Connector
Headers
Header Name Description
FP_AUDIO Front Panel Audio Header 9-pin Block
HDMI_SPDIF HDMI_SPDIF Out Header 2-pin Block
GPIO_CON GPIO Header 10-pin Block
PARALLEL Parallel Port Header 25-pin Block
JW_FP
(Front Panel Header)
PWR LED/ HD LED/
Power Button /Reset
9-pin Block
PWRLED1 Power LED Header 3-pin Block
SPEAK1 Speaker Header 4-pin Block
USB2
(optional for NLH61 & NLH61-6C)
USB 2.0 Header 9-pin Block
USB3 USB 2.0 Header 9-pin Block
USB3_1/USB3_2
(optional for NLB75)
USB 3.0 Header 19-pin Block
COM 2/4/5/6 Serial Port Header 9-pin Block
COM7/8/9/10
(optional for NLH61 & NLB75)
Serial Port Header 9-pin Block
CPUFAN1 CPUFAN Header 4-pin Block
SYSFAN1/SYSFAN2 System FAN Header 3-pin Block
