Intel H61 User Manual

4
For NLB75 Series:
*Note:
The main differences between NLH61 and model NLB75 are listed as below:
Model Chipset SATA Port USB 2.0 Header
USB 3.0 Header
NLH61
Intel H61
4* SATA Port 2 * header None
NLB75
Intel B75
1* SATAIII Port +
3 SATAII
1 * header 2 * header
The diagrams used for illustration in this manual are from model NLH61, unless
otherwise stated.
ATX 12V
Power Connector
ATX Power
Connector
CPU Socket
Audio Connectors
VGA Port over
DVI–D Port
RJ-45 LAN Ports
Over USB 2.0 Ports
RJ-45 LAN Ports
Over USB 2.0 Ports
PCI Express x16 Slot (PE1)
PCI Ex
press 2.0 x1
Slot
(
PE2
)
32
-
bit
PCI Slot
s
F
ront Panel
Audio
Header
Parallel
Header
Intel B75
Chipset
USB 3.0 Headers
Front Panel Header
DDRIII
DIMM
Slot
x
2
Full
-
size
Mini-PCIE Slot
(Mini-PCIE) *
GPIO Header
SYS
FAN
1 H
eader
CPUFAN
Header
Serial Ports
(
COM2/4/7/
8/6/5/10/9)
SATAII Ports
(SATA2/3/4)
HDMI S/PDIF Header
Speaker Header
PS/2 Mouse Port over
PS/2 Keyboard Port
Serial Ports
PWR LED Header
SYS
FAN
2
H
eader
USB 2.0 Header
SATAIII Port
(SATA1)
