Intel® Server S2600CW Product Family Configuration Guide and Spares/Accessories List
9
Intel Product Code
(iPC)
Order Information Product Description Product Type
iPC – DBS2600CW2SR
MM# - 943804
UPC -
00735858309226
EAN -
5032037081818
MOQ - 5
Board Dimensions:
SSI EEB 12" x 13"
Packaged Gross Weight
(Five boards package)
10.7 Kgs, 23.6 Lbs
Un-packaged Net Weight
(Single board)
1.41 Kgs, 3.11 Lbs
Intel
®
Server Board S2600CW2SR
• Support for dual Intel
®
Xeon E5-2600 v3 and v4 processor families
• Intel® C612 Chipset
• 16 DDR4 DIMM Slots
• Dual Integrated 1Gb ports with Intel
®
Virtualization Technology
• Integrated Baseboard Management controller with IPMI 2.0 support
• Optional advanced management features activated by AXXRMM4LITE key
• Dedicated management port onboard
• 6 PCIe* slots
o One x4 PCIe* Gen 2 from PCH
o One x8 PCIe* Gen 3 from CPU 0
o One x8 PCIe* Gen3 from CPU 1
o One x16 PCIe* Gen 3 from CPU 0
o Two x16 PCIe* Gen 3 from CPU 1
• LSI 3008 Battery-less 12G SAS hardware RAID
• 8 SATA through 2 Mini SAS HD ports
• 2 SATA 6G AHCI ports
•
8 SAS through 2 Mini-SAS HD ports from LSI3008
Server Board only
• Building block
option
• Spare FRU
iPC – DBS2600CWTSR
MM# - 943806
UPC -
00735858309233
EAN -
5032037081825
MOQ - 5
Board Dimensions:
SSI EEB 12" x 13"
Packaged Gross Weight
(Five boards package)
10.7 Kgs, 23.6 Lbs
Un-packaged Net Weight
(Single board)
1.375 Kgs, 3.03 Lbs
Intel
®
Server Board S2600CWTSR
• Support for dual Intel
®
Xeon E5-2600 v3 and v4 processor families
• Intel® C612 Chipset
• 16 DDR4 DIMM Slots
• Dual Integrated 10Gb ports with Intel
®
Virtualization Technology
• 2 PCIe* 3.0 x24 capable slots and 2 PCIe* 3.0 x16 capable slot (not PCI-SIG*
compatible)
• Integrated Baseboard Management controller with IPMI 2.0 support
• Optional advanced management features activated by AXXRMM4LITE key
• Dedicated management port onboard
• 6 PCIe* slots
o One x4 PCIe* Gen 2 from PCH
o One x8 PCIe* Gen 3 from CPU 0
o One x8 PCIe* Gen3 from CPU 1
o One x16 PCIe* Gen 3 from CPU 0
o Two x16 PCIe* Gen 3 from CPU 1
• LSI 3008 Battery-less 12G SAS hardware RAID
• 8 SATA through 2 Mini SAS HD ports
• 2 SATA 6G AHCI ports
•
8 SAS through 2 Mini-SAS HD ports from LSI3008
Server Board only
• Building block
option
• Spare FRU
