Intel P4304XXMUXX Spares/Accessories List And Configuration Guide

Intel® Server S2600CW Product Family Configuration Guide and Spares/Accessories List
15
Cable Kit Product Code Example - AXXCBL950HDMS
AXXCBL – Identifies an accessory cable kit
950 – identifies the length of the cable in millimeters
HD – identifies that one end of cable connector has SFF-8643 connector
MS – identifies that the other end of cable connector has SFF-8087 connector
7[S|R|P] – identifies that the other end of cable connector has single port SATA
Drive numbering in the system illustrations is for general reference only. Actual drive numbering will be dependant on SAS / SATA controller configuration and
how they are cabled to the backplane. Each installed backplane will include a multi-port data connector for each for drive group.
Each table in the following sections identifies the cable connections and recommended cable lengths for each supported storage controller option in the
specified system. Each “recommended” cable length for a given connector pair provides enough cable to attach the two devices with the least amount of
excess cable, resulting in the cleanest cable routing. See Table 19. Storage Data Cable Kit Description and Order Information for appropriate cable kits to use on
your system.
3.2.1 Fixed HDDs SAS/SATA Cable Guide
One Mini-SAS cable - iPC AXXCBL450HD7S is included in the server chassis while the other cables must be ordered separately, as needed.
One addtional set of HDD trays - iPC FUP4X35NHDK is needed for a fixed 8x3.5” or fixed 8x2.5” hard drive configuration since the Intel® Server Chassis is
shipped with only 4 HDD trays.
Table 10. Fixed HDD Configuration SATA Cable Guide
Drive
Support
Cables for On-Board SATA Capable
Controller to Hard Drive
Cables for On-Board SAS Controller
on S2600CW2SR or S2600CWTSR to
Hard Drive
Cables for 12 Gb SAS RAID
PCIe* add-in card to Hard
Drive
Cables for 6 Gb SAS RAID
PCIe* add-in card to Hard
Drive
Fixed
4x3.5”
Cable Connections:
SATA -> HDD
450mm HD --- 7S
(1) AXXCBL450HD7S
Cable included with the server chassis
Cable Connections:
SAS onboard-> HDD
450mm HD ---
7S
(1) AXXCBL450HD7S
Cable included with the server chassis
Cable Connections:
SAS Add-in card -> HDD
900mm HD ---
7S
(1) AXXCBL900HD7R
Cable must be ordered
separately. The kit includes
two cables
Cable Connections:
SAS Add-in card -> HDD
740mm MS ---
7S
(1) AXXCBL740MS7P
Cable must be ordered
separately. The kit includes
two cables
