Intel® Server S2600CW Product Family Configuration Guide and Spares/Accessories List
11
Table 5. Intel® Server Chassis P4000 Product Family SKUs
Intel Product Code (iPC):
iPC – P4304XXMFEN2
Order Code Information:
MM# - 936416
UPC - 00735858292658
EAN - 5032037070980
MOQ - 1
Product Type: Chassis Only
Chassis Form Factor: 4U Pedestal mount
(Rackable)
Chassis dimensions: L=612mm, W=173mm,
H=438mm
Packaged Gross Weight: 21.8 Kgs, 48 Lbs
Un-packaged Net Weight: 16 Kgs, 35.2 Lbs
Outer Box Dimensions: L=813mm, W=348mm,
H=577mm
Product Definition and Configuration Requirements
Intel product code P4304XXMFEN2 includes the
following components:
(1) - 4U Pedestal Chassis
(1) - Standard Control Panel – iPC FXXFPANEL
(1) - Fixed 550W PSU – iPC FUP550SNRPS
(4) - Fixed 3.5”/2.5” drive sleds - iPC FUP4X35NHDK
(1) - Fixed 120mm system fan - iPC FUPNHFANCPU
(1) - Fixed 120mm system fan - iPC FUPMNHFANPCI
(1) - Processor/Memmory air duct – iPC A4UCWDUCT
(1) - Fixed bezel – iPC FUPBEZELFIX2
(1) - Attention documention
(2) – Dual power Connector Cable iPN – G22872-00x
(1) – MiniSAS HD to 4 ports SATA 7 pins cable – iPN
H19948-00x
(1) – Chassis plastic Foot iPN – G35111-00x
(1) – Set of standoffs for Motherboard iPN – G35101-
00x
(1) – Bumper pad for Motherboard iPN – G35112-00x
(1) – Set of 5mm screws for Motherboad iPN – G35096
Required Items – Sold Separately:
• Intel® Server Board S2600CW (choose one)
o iPC DBS2600CW2R – with dual 1GbE NIC
ports
o iPC DBS2600CWTR – with dual 10GbE NIC
ports
o iPC DBS2600CW2SR – with dual 1GbE NIC
ports and onboard SAS controller
o iPC DBS2600CWTSR – with dual 10GbE NIC
ports and onboard SAS controller
• Power Cord(s)
NOTE: Chassis shipped to the US & Canada
will contain North American power cords.
• 1 or 2 Intel® Xeon® E5-2600 v3 or v4 product family
processors
• ECC DDR4 memory (RDIMM)
•
SATA cables
Optional Intel Accessories – Sold Separately:
• Intel® I/O Module – See Chapter 5 for options.
• Intel® SAS RAID Card / Module – See Section 4.3 for
options.
• Rack options - See 4.5 Section for options.
• iPC AXXRMM4LITE – Intel® Remote Management
Module Lite key. For advanced management
features
• Storage Drives
See Chapter 4 for all available accessory options.
