Intel® Server S1200SP Family Configuration Guide
12
Intel® Product Code (iPC):
P4304XXSHCN
Pedestal Chassis – 4 x 3.5” Hot Swap Drives, 1 x 365W power
Order Code
Information:
MM# - 911765
UPC - 00735858219365
EAN - 5032037016940
MOQ - 1
Product Type: Chassis Only
Chassis Form Factor: Pedestal
Chassis dimensions: L=560 mm, W=438 mm, H=173 mm
Packaged Gross Weight: 18.9 Kgs, 41.6 Lbs
Un-packaged Net Weight: 17.1 Kgs, 37.7 Lbs
Outer Box Dimensions: L=698mm, W=553mm, H=375mm
Product Definition and Configuration Requirements
Intel® product code P4304XXSHCN includes the following
components:
(1) Pedestal Chassis
(1) Front Panel assembly with cables
(1) 365W Fixed Mount Power Supply
(1) System fan assembly
(1) 4 x 3.5” drive hot swap
(4) 3.5” Hot swap drive carriers
(4) Plastic chassis foot paddle
(2) ODD Slide Rail Assemblies
(1) 450mm SATA data cable
(1) 600mm I2C data cable
(1) 450mm SGPIO data cable
(1) 200mm chassis intrusion switch cable
(1) Quick Install Users Guide
(1 set) Server board mount rubber bumpers
(1 set) Server board mounting screws
Required Items – Sold Separately:
• Intel® Server Board S1200SP (choose one)
o S1200SPL
o S1200SPS
• Power Cord(s)
• 1 Boxed w/Heatsink Intel processor (choose
one)
o Intel® Xeon® Processor E3-1200 v5
product family
o Intel® Core® processor i3 product family
• DDR4 memory (UDIMM)
Optional Intel® Accessories – Sold
Separately:
• SATA/SAS data cables. See Section 4.2 for
more information.
See Chapter 5 for all available accessory options.

Intel S1200SP Specifications

General

PCI Express Revision	3.0
Instruction Set	64-bit
Network	Dual Gigabit Ethernet
Number of Threads	Varies by CPU
Bus Speed	Varies by CPU
TDP	Varies by CPU
Instruction Set Extensions	Intel® SSE4.2
Thermal Solution Specification	Varies by CPU
