Intel® Server S1200SP Family Configuration Guide
13
Intel® Product Code (iPC):
P4000XXSFDR
Pedestal Chassis – 4 x 3.5” Fixed Mount Drives, Dual 460W
power
Order Code
Information:
MM - 944468
UPC - 00735858306485
EAN - 5032037079945
MOQ - 1
Product Type: Chassis Only
Chassis Form Factor: Pedestal
Chassis dimensions: L=560mm, W=438mm, H=173mm
Packaged Gross Weight: 17.1 Kgs, 37.7 Lbs
Un-packaged Net Weight: 14.6 Kgs, 32.2 Lbs
Outer Box Dimensions: L=698mm, W=553mm, H=375mm
Product Definition and Configuration Requirements
Intel® product code P4000XXSFDR includes the following
components:
(1) Pedestal Chassis
(1) Front Panel assembly with cables
(2) 460W Power Supply Modules
(1) System rear fan assembly
(1) System PCIe zone fan assembly
(4) fixed mount drive trays
(4) Plastic chassis foot paddle
(2) ODD Slide Rail Assemblies
(1) 200mm chassis intrusion switch cable
(2) 150mm dual SATA Drive power cable
(1) SATA cable for onboard M.2 connector
(1) USB 3.0 cable
(1 set) Server board mount rubber bumpers
(1 set) Server board mounting screws
Required Items – Sold Separately:
• Intel® Server Board S1200SP (choose one)
o S1200SPL
o S1200SPS
• Power Cord(s)
• 1 Boxed w/Heatsink Intel® processor (choose
one)
o Intel® Xeon® Processor E3-1200 v5
product family
o Intel® Core® processor i3 product
family
• DDR4 memory (UDIMM)
Optional Intel® Accessories – Sold
Separately:
• SATA/SAS data cables. See Section 4.2 for
more information.
See Chapter 5 for all available accessory options.

Intel S1200SP Specifications

General

PCI Express Revision	3.0
Instruction Set	64-bit
Network	Dual Gigabit Ethernet
Number of Threads	Varies by CPU
Bus Speed	Varies by CPU
TDP	Varies by CPU
Instruction Set Extensions	Intel® SSE4.2
Thermal Solution Specification	Varies by CPU
