6 Intel
®
Server Board S5500BC User’s Guide
2-3 If these pins are jumpered, the CMOS
settings are cleared on the next reset.
NOTE: These pins should not be jumpered
for normal operation.
J1A1: BIOS Recovery 1-2 These pins should have a jumper in place
for normal system operation.(Default)
2-3 The main system BIOS will not boot with
these pins jumpered.
NOTE: The system will boot from EFI-
bootable recovery media with a
recovery BIOS image.
J8B5: ME Force Update 1-2 These pins should have a jumper in place
for normal system operation. (Default)
2-3 ME force update model.
Jumper Name Pins What happens at system reset...
