Intel VS440FX - Motherboard Connectors

VS440FX Motherboard Technical Product Specification
20
1.11 Motherboard Connectors
The following figure shows the connectors on the motherboard.
Secondary
Primary
OM05523
Simm
Socket(4)
1(J3G1, J3G2)
0 (J3H1, J3H2)
J2D1, J2D2
J2E1, J2F1
PCI
Connectors(4)
J1A1, J1B1
J1B2, J1C1
ISA
Connectors(4)
1
3
J9A1
Aux Fan
Connector
14
J1E2
CDROM
Connector
1
J1E1
Wave Table
Connector
2
J1F1
Telephony
Connector
1
13
J7M1
CPU Fan
Connector
1
10
11
20
J5M1
Power
Connector
J9J2
2 34
1 335
Floppy Drive Connector
PCI IDE Connector(2)
139
24020
J8J1
J9J1
Front Panel I/O Connector
J10H1
27 1
Figure 4. Motherboard Connectors
