Intel VS440FX - CD Audio (J1 E2); Wavetable Upgrade Connector (J1 E1); Telephony Connector (J1 F1)

Motherboard Description
21
1.11.1 CD Audio (J1E2)
Pin Signal Name
1 Ground
2 CD audio left channel
3 Ground
4 CD audio right channel
1.11.2 Wavetable Upgrade Connector (J1E1)
Pin Signal Name
1 Wave in right
2 Ground
3 Wave in left
4 Ground
5 No connection
6 Ground
7 No connect
8 MIDI_Out
1.11.3 Telephony Connector (J1F1)
Pin Signal Name
1 Ground
2 Audio out
3 Audio in
4 Key
