Intelligent Home CAT-5 Series User Manual

4.6 Two Doorbell B Multiple monitors connection
Power
Supply
Distributor 4230
1# Monitor
3# Monitor
2# Monitor
PORT3
Down linkUp link
Power
DC+ GND AF+ AF- VF+ VF- LB LA
PORT2 PORT1
doorbell2 doorbell1
DC+ GND AF+ AF- VF+ VF- LB LA PS GND DC+
+
-
Brown
Brown/white
Blue
Blue/white
Green
Green/white
Orange
Orange/white
LA LB VF- VF+ VF- AF+ GND DC+
Note 1
Note 1
Brown
Brown/white
Blue
Blue/white
Green
Green/white
Orange
Orange/white
LA LB VF- VF+ VF- AF+ GND DC+
Note 1: Power to the doorbell can be connected either from 4001 power supply or 4230 LAN switch. Note 2: Remove the jumper for multiple monitor systems.
12345678
8. Brown 7. Brown/white 6. Green 5. Blue/white 4. Blue 3. Green/white 2. Orange 1. Orange/white
12345678
Note 2
Doorbell back view
Note 2
Doorbell back view
Note 3
Note 3: This connector is for lock connection. See lock connection diagram.
-11-
