Intellinet 524438 User Manual

802 .1x se t t i n g /Ce r t i F i C a t i o n
 The EAP authentication protocols supported by this
adapter require that settings be consistent with the wireless access
points or routers that the adapter is intended to connect.
 These protocols are similar and easier to use than
TLS (below) in that they specify a stand-alone authentication protocol
to be used within an encrypted tunnel. TTLS supports any protocol
within its tunnel, including CHAP, MS-CHAP, MS-CHAPv2, PAP and
EAP-MD5. PEAP species that an EAP-compliant authentication
protocol be used; this adapter supports EAP-MSCHAP v2, EAP-TLS/
Smart Card and Generic Token Card. The client certicate is optional.
 This is the most secure of the EAP protocols, but
isn’t easy to use: It requires that digital certicates be exchanged in
16
CONFIGURATION
RADIUS
Server
Windows 2000 IAS
(Internet Authentication
Service)
IEEE 802.1x
Access Client
Access Point
RADIUS
Client
1
2
3
4
(2) Login with username,
password.
(1) Client requests to login the
network.
(4) Approve or deny user
login to the LAN.
(3) Send username, password to
RADIUS server.
1
2
4
3
1 Client requests to log in to the network 3 Username and password sent to RADIUS server
2 Log in with username and password 4 User login to the LAN approved or denied
IEEE 802.1x Access Client RADIUS Client RADIUS Server
