Ref No. Part No. ValueDescription
R301 3009683973 RES 1/5W 5% 68K
R302 3009221973 RES 1/5W 5% 220
R303 3009104973 RES 1/5W 5% 100K
R304 3009222973 RES 1/5W 5% 2.2K
R305 3009472973 RES 1/5W 5% 4.7K
R306 3009272973 RES 1/5W 5% 2.7K
R307 3009332973 RES 1/5W 5% 3.3K
R308 3009473973 RES 1/5W 5% 47K
R309 3009750973 RES 1/5W 5% 75
R310 3009152973 RES 1/5W 5% 1.5K
R311 3009122973 RES 1/5W 5% 1.2K
R351 3009561973 RES 1/5W 5% 560
R352 3009563973 RES 1/5W 5% 56K
R353 3009561973 RES 1/5W 5% 560
R354 3009563973 RES 1/5W 5% 56K
R355 3009561973 RES 1/5W 5% 560
R356 3009563973 RES 1/5W 5% 56K
R357 3009561973 RES 1/5W 5% 560
R358 3009563973 RES 1/5W 5% 56K
R359 3009561973 RES 1/5W 5% 560
R360 3009563973 RES 1/5W 5% 56K
R361 3009561973 RES 1/5W 5% 560
R362 3009563973 RES 1/5W 5% 56K
R363 3009561973 RES 1/5W 5% 560
R364 3009563973 RES 1/5W 5% 56K
R365 RES 1/5W 5% FR 100
R366 3009302973 RES 1/5W 5% 3K
R367 3009302973 RES 1/5W 5% 3K
R368 3009302973 RES 1/5W 5% 3K
R369 3009102973 RES 1/5W 5% 1K
R370 3009103973 RES 1/5W 5% 1K
R371 3009103973 RES 1/5W 5% 1K
R372 3009103973 RES 1/5W 5% 1K
R373 3009303973 RES 1/5W 5% 30K
R374 3009203973 RES 1/5W 5% 20K
R375 3009823973 RES 1/5W 5% 82K
R376 3009683973 RES 1/5W 5% 68K
R377 3009823973 RES 1/5W 5% 82K
C301 3409210142-T CAP ( E ) 100UF / 25V
C302 3509221231-A CAP ( C ) 220P
C303 3529680311-A CAP ( C ) 68P
C304 3409247071-T CAP ( E ) 47UF / 50V
C305 3409222071-T CAP ( E ) 22UF / 50V
C306 3529103531-A CAP ( C ) 10000P
C307 3509331231-A CAP ( C ) 330P
C308 3529470311-A CAP ( C ) 47P
C309 3409222071-T CAP ( E ) 22UF / 50V
C310 3509471231-A CAP ( C ) 470P
C311 3409210142-T CAP ( E ) 100UF / 25V
C312 3509101231-A CAP ( C ) 100P
C313 3409247071-T CAP ( E ) 47UF / 50V
C351 3639184111-T CAP ( M ) 0.18UF / 50V
C352 3409210973-T CAP ( E ) 1UF / 50V
C353 3609683120-T CAP ( M ) 683 / 100V
C354 3639394111-T CAP ( C ) 0.39 / 50V
C355 3609273120-T CAP ( M ) 273 / 100V
C356 3639184111-T CAP ( M ) 0.18UF / 50V
C357 3609123120-T CAP ( M ) 123 / 100V
C358 3609683120-T CAP ( M ) 683 / 100V
C359 3609472120-T CAP ( M ) 472 / 100V
C360 3609273120-T CAP ( M ) 273 / 100V
C361 3609182120-T CAP ( M ) 182 / 100V
C362 3609103120-T CAP ( M ) 103 / 100V
C363 3509821130-T CAP ( C ) 820P
C364 3609472120-T CAP ( M ) 472 / 100V
C365 3409210142-T CAP ( E ) 100UF / 25V
C366 3409247971-T CAP ( E ) 4.7UF / 50V
C367 3409247971-T CAP ( E ) 4.7UF / 50V
C368 3409247971-T CAP ( E ) 4.7UF / 50V
IC301 2168220989 I . C OP AMP NJM2068L
IC302 2168220989 I . C OP AMP NJM2068L
IC303 2118010590 I . C OP AMP NJM4580D
IC351 2118010590 I . C OP AMP NJM4558D
IC352 2118010590 I . C OP AMP NJM4558D
Ref No. Part No. ValueDescription
IC353 2118010590 I . C OP AMP NJM4558D
IC354 2118010590 I . C OP AMP NJM4558D
IC355 2118010590 I . C OP AMP NJM4558D
IC356 2118010590 I . C OP AMP NJM4558D
IC357 2118010590 I . C OP AMP NJM4558D
IC358 2118030405 I . C LEVEL 6966S
IC359 2118030405 I . C LEVEL 6966S
VR301 3228077210 VOLUME 20KA x 2
VR351 3238080010 VOLUME SLIDE 20KW X 2
VR352 3238080010 VOLUME SLIDE 20KW X 2
VR353 3238080010 VOLUME SLIDE 20KW X 2
VR354 3238080010 VOLUME SLIDE 20KW X 2
VR355 3238080010 VOLUME SLIDE 20KW X 2
VR356 3238080010 VOLUME SLIDE 20KW X 2
VR357 3238080010 VOLUME SLIDE 20KW X 2
JK301 4438192910 OUT BA PHONE
LD351 2300032100 LED GRE
LD352 2300032100 LED GRE
LD353 2300032100 LED GRE
LD354 2300032100 LED GRE
LD355 2300031100 LED YEL
LD356 2300031100 LED YEL
LD357 2300031100 LED YEL
R401 3009683973 RES 1/5W 5% 68K
R402 3009221973 RES 1/5W 5% 220
R403 3009104973 RES 1/5W 5% 100K
R404 3009222973 RES 1/5W 5% 2.2K
R405 3009472973 RES 1/5W 5% 4.7K
R406 3009272973 RES 1/5W 5% 2.7K
R407 3009332973 RES 1/5W 5% 3.3K
R408 3009473973 RES 1/5W 5% 47K
R409 3009750973 RES 1/5W 5% 75
R410 3009152973 RES 1/5W 5% 1.5K
R411 3009122973 RES 1/5W 5% 1.2K
R451 3009561973 RES 1/5W 5% 560
R452 3009563973 RES 1/5W 5% 56K
R453 3009561973 RES 1/5W 5% 560
R454 3009563973 RES 1/5W 5% 56K
R455 3009561973 RES 1/5W 5% 560
R456 3009563973 RES 1/5W 5% 56K
R457 3009561973 RES 1/5W 5% 560
R458 3009563973 RES 1/5W 5% 56K
R459 3009561973 RES 1/5W 5% 560
R460 3009563973 RES 1/5W 5% 56K
R461 3009561973 RES 1/5W 5% 560
R462 3009563973 RES 1/5W 5% 56K
R463 3009561973 RES 1/5W 5% 560
R464 3009563973 RES 1/5W 5% 56K
R465 3009302973 RES 1/5W 5% 3K
R466 3009302973 RES 1/5W 5% 3K
R467 3009302973 RES 1/5W 5% 3K
R468 3009102973 RES 1/5W 5% 1K
R469 3009102973 RES 1/5W 5% 1K
R470 3009102973 RES 1/5W 5% 1K
R471 3009102973 RES 1/5W 5% 1K
R472 3009303973 RES 1/5W 5% 30K
R473 3009203973 RES 1/5W 5% 20IK
R474 3009823973 RES 1/5W 5% 82K
R475 3009683973 RES 1/5W 5% 68K
R476 3009823973 RES 1/5W 5% 82K
R477 3009103973 RES 1/5W 5% 10K
R478 3009103973 RES 1/5W 5% 10K
R479 3009103973 RES 1/5W 5% 10K
R480 3009103973 RES 1/5W 5% 10K
R481 3009103973 RES 1/5W 5% 10K
C401 3409210142-T CAP ( E ) 100UF / 25V
C402 3509221231-A CAP ( C ) 220P
C403 3529680311-A CAP ( C ) 68P
C404 3409247071-T CAP ( E ) 47UF / 50V
C405 3409222071-T CAP ( E ) 22UF / 50V
C406 3529103531-A CAP ( C ) 10000P
C407 3509331231-A CAP ( C ) 330P
C408 3529470311-A CAP ( C ) 47P
C409 3409222071-T CAP ( E ) 22UF / 50V
C410 3509471231-A CAP ( C ) 470P
C411 3409210142-T CAP ( E ) 100UF / 25V
Ref No. Part No. ValueDescription
C412 3509101231-A CAP ( C ) 100P
C413 3409247071-T CAP ( E ) 47UF / 50V
C451 3409210973-T CAP ( E ) 1UF / 50V
C452 3639184111-T CAP ( C ) 0.18UF / 50V
C453 3639394111-T CAP ( C ) 0.39 / 50V
C454 3609683120-T CAP ( M ) 683 / 100V
C455 3639184111-T CAP ( C ) 0.18UF / 50V
C456 3609273120-T CAP ( M ) 273 / 100V
C457 3609683120-T CAP ( M ) 683 / 100V
C458 3609123120-T CAP ( M ) 123 / 100V
C459 3609273120-T CAP ( M ) 273 / 100V
C460 3609472120-T CAP ( M ) 472 / 100V
C461 3609103120-T CAP ( M ) 103 / 100V
C462 3609182120-T CAP ( M ) 182 / 100V
C463 3609472120-T CAP ( M ) 472 / 100V
C464 3509821130-T CAP ( C ) 820P
C465 3529103531-A CAP ( C ) “10,000P”
C466 3529103531-A CAP ( C ) “10,000P”
C467 3529103531-A CAP ( C ) “10,000P”
C468 3529103531-A CAP ( C ) “10,000P”
C469 3529103531-A CAP ( C ) “10,000P”
C470 3529103531-A CAP ( C ) “10,000P”
C471 3529103531-A CAP ( C ) “10,000P”
C472 3529103531-A CAP ( C ) “10,000P”
C473 3529103531-A CAP ( C ) “10,000P”
C474 3529103531-A CAP ( C ) “10,000P”
C475 3529103531-A CAP ( C ) “10,000P”
C476 3529103531-A CAP ( C ) “10,000P”
C477 3529103531-A CAP ( C ) “10,000P”
C478 3529103531-A CAP ( C ) “10,000P”
C479 3409247971-T CAP ( E ) 4.7UF / 50V
C480 3409247971-T CAP ( E ) 4.7UF / 50V
C481 3409247971-T CAP ( E ) 4.7UF / 50V
C482 3409222071-T CAP ( E ) 22UF / 50V
C483 3409222071-T CAP ( E ) 22UF / 50V
C484 3529470311-A CAP ( C ) 47P
C485 3409222071-T CAP ( E ) 22UF / 50V
C486 3529470311-A CAP ( C ) 47P
C487 3409222071-T CAP ( E ) 22UF / 50V
IC451 2118030405 I . C LEVEL 6966S
IC452 2118030405 I . C LEVEL 6966S
IC453 2168220989 I . C OP AMP NJM2068D
JK401 4438192910 OUTPUT JACK PHONE
LD451 2300032100 LED GRE
LD452 2300032100 LED GRE
LD453 2300032100 LED GRE
LD454 2300032100 LED GRE
LD455 2300031100 LED YEL
LD456 2300031100 LED YEL
LD457 2300031100 LED YEL
SW451 4618999210 SLIDE SWITCH 3P X 2
R1 3009105973 RES 1/5W 5% 1M
R2 3009471973 RES 1/5W 5% 470
R3 3009103973 RES 1/5W 5% 10K
R4 3009473973 RES 1/5W 5% 47K
R5 3009473973 RES 1/5W 5% 47K
R6 3009104973 RES 1/5W 5% 100K
R7 3009222973 RES 1/5W 5% 2.2K
R8 3009222973 RES 1/5W 5% 2.2K
R9 3009222973 RES 1/5W 5% 2.2K
R10 3009202973 RES 1/5W 5% 2 K
R11 3009222973 RES 1/5W 5% 2.2K
R12 3009222973 RES 1/5W 5% 2.2K
R13 3009222973 RES 1/5W 5% 2.2K
R14 3009222973 RES 1/5W 5% 2.2K
R15 3009222973 RES 1/5W 5% 2.2K
R16 3009222973 RES 1/5W 5% 2.2K
R17 3009222973 RES 1/5W 5% 2.2K
R18 3009222973 RES 1/5W 5% 2.2K
R19 3009101973 RES 1/5W 5% 100
R20 3009104973 RES 1/5W 5% 100K
R21 3009103973 RES 1/5W 5% 10K
R22 3009103973 RES 1/5W 5% 10K
R23 3009103973 RES 1/5W 5% 10K
Ref No. Part No. ValueDescription
R24 3009103973 RES 1/5W 5% 10K
R25 3009103973 RES 1/5W 5% 10K
R113 3009222973 RES 1/5W 5% 2.2K
R114 3009222973 RES 1/5W 5% 2.2K
R115 3009222973 RES 1/5W 5% 2.2K
R116 3009222973 RES 1/5W 5% 2.2K
R117 3009222973 RES 1/5W 5% 2.2K
R118 3009222973 RES 1/5W 5% 2.2K
R119 3009101973 RES 1/5W 5% 100
R120 3009104973 RES 1/5W 5% 100K
R121 3009103973 RES 1/5W 5% 10K
R122 3009103973 RES 1/5W 5% 10K
D1 2058304100 DIODE 1N4148
D2 2058304100 DIODE 1N4148
D3 2058304100 DIODE 1N4148
D4 2058304100 DIODE 1N4148
D5 2058304100 DIODE 1N4148
C1 3609104120-T CAP ( C ) 104 / 50V
C2 3609104120-T CAP ( C ) 104 / 50V
C3 3509220130-T CAP ( C ) 22P
C4 3509220130-T CAP ( C ) 22P
C5 3409247971-T CAP ( E ) 4.7UF / 50V
C6 3509332530-T CAP ( C ) 332 / 50V
C7 3509332530-T CAP ( C ) 332 / 50V
C8 3409210142-T CAP ( E ) 100UF / 25V
C9 3409247971-T CAP ( E ) 4.7UF / 50V
C10 3409247971-T CAP ( E ) 4.7UF / 50V
C11 3409210142-T CAP ( E ) 100UF / 25V
C12 3609104120-T CAP ( C ) 104 / 50V
C13 3409210071-T CAP ( E ) 10UF / 50V
C14 3609104120-T CAP ( C ) 104 / 50V
C15 3409210071-T CAP ( E ) 10UF / 50V
C16 3609152120-T CAP ( M ) 152 / 100V
C17 3609273120-T CAP ( M ) 273 / 100V
C18 3609103120-T CAP ( M ) 103 / 100V
C19 3609103120-T CAP ( M ) 103 / 100V
C20 3609273120-T CAP ( M ) 273 / 100V
C21 3609152120-T CAP ( M ) 152 / 100V
C22 3509221231-A CAP ( C ) 220P
C23 3409210071-T CAP ( E ) 10UF / 50V
C24 3609103120-T CAP ( M ) 103 / 100V
C25 3609273120-T CAP ( M ) 273 / 100V
C26 3609152120-T CAP ( M ) 152 / 100V
C27 3609103120-T CAP ( M ) 103 / 100V
C28 3609273120-T CAP ( M ) 273 / 100V
C29 3609152120-T CAP ( M ) 152 / 100V
C30 3409210071-T CAP ( E ) 10UF / 50V
C31 3509104530-T CAP ( C ) 104 / 50V
C32 3509104530-T CAP ( C ) 104 / 50V
C33 3509104530-T CAP ( C ) 104 / 50V
C34 3509104530-T CAP ( C ) 104 / 50V
C35 3509104530-T CAP ( C ) 104 / 50V
C36 3509104530-T CAP ( C ) 104 / 50V
C37 3509104530-T CAP ( C ) 104 / 50V
C38 3509104530-T CAP ( C ) 104 / 50V
C122 3509221231-A CAP ( C ) 220P
C123 3409210071-T CAP ( E ) 10UF / 50V
C124 3609103120-T CAP ( M ) 103 / 100V
C125 3609273120-T CAP ( M ) 273 / 100V
C126 3609152120-T CAP ( M ) 152 / 100V
C127 3609103120-T CAP ( M ) 103 / 100V
C128 3609273120-T CAP ( M ) 273 / 100V
C129 3609152120-T CAP ( M ) 152 / 100V
C130 3409210071-T CAP ( E ) 10UF / 50V
IC1 2128130600 I . C YSS220
IC2 2128420007 I . C KM62256DLG-7L
IC3 2168220989 I . C 2068L
IC4 2168220989 I . C 2068L
IC5 2168220989 I . C 2068L
IC15 2168220989 I . C 2068L
Q1 2008606104-T T . R 3198BL
X1 3938000965 X - TAL 12.288MHZ
FL1 3908609990 FILTER 1000P
CN1 1099900005-J CON ASS’Y 5P
CN2 1099900007-J CON ASS’Y 7P
CN3 1099900004-J CON ASS’Y 4P
DISPLAY
MAIN L, R (OUT, EQ, LEVEL), REC OUT
