9
Ref No. Part No. ValueDescription
R401 3039479572-F FR 4.7 2W
R402 3009332973 RES 1/5W 5% 3.3K
R403 3009471973 RES 1/5W 5% 470
R404 3009122973 RES 1/5W 5% 1.2K
R405 3009122973 RES 1/5W 5% 3.3k
C401 3619474153 CAP S.P.K 0.47UF / 250V
C402 3619474153 CAP S.P.K 0.47UF / 250V
C403 3419510350 CAP ( E ) “10,000UF / 80V”
C404 3419510350 CAP ( E ) “10,000UF / 80V”
C405 3509103450-T CAP ( C ) 0.01UF / 500V
C406 3509103450-T CAP ( C ) 0.01UF / 500V
C407 3509103450-T CAP ( C ) 0.01UF / 500V
C408 3509103450-T CAP ( C ) 0.01UF / 500V
C409 3419233261 CAP ( E ) “3,300UF / 35V”
C410 3419233261 CAP ( E ) “3,300UF / 35V”
C411 3509103530-T CAP ( C ) 0.01UF / 50V
C412 3509103530-T CAP ( C ) 0.01UF / 50V
C413 3409222171-T CAP ( E ) 220UF / 50V
C414 3409222171-T CAP ( E ) 220UF / 50V
C415 3509103530-T CAP ( C ) 0.01UF / 50V
C416 3509103530-T CAP ( C ) 0.01UF / 50V
C417 3509103450-T CAP ( C ) 0.01UF / 500V
C418 3509103450-T CAP ( C ) 0.01UF / 500V
C419 3509103450-T CAP ( C ) 0.01UF / 500V
C420 3509103450-T CAP ( C ) 0.01UF / 500V
C421 3409210208 CAP ( E ) “1,000UF / 80V”
C422 3409210181-T CAP ( E ) 100UF / 63V
C423 3509103450-T CAP ( C ) 0.01UF / 500V
C424 3509103450-T CAP ( C ) 0.01UF / 500V
C425 3509103450-T CAP ( C ) 0.01UF / 500V
C426 3509103450-T CAP ( C ) 0.01UF / 500V
C427 3409210264 CAP ( E ) “1,000UF / 35V”
C428 3409210071-T CAP ( E ) 10UF / 50V
C429 3409247071-T CAP ( E ) 47UF / 50V
C430 3409247147-T CAP ( E ) 470UF / 25V
C431 3409210141-T CAP ( E ) 100UF / 25V
IC401 2128611206 I . C REG 7805
IC402 2128610900 I . C REG 7815
IC403 2128610800 I . C REG 7915
Q401 2028407990 T . R 2SC4370
Q402 2028407990 T . R 2SC4370
Q403 2008606108-T T . R KTC2240BL
D401 2058100988 BRIDGE DIODE KBP2504
D402 2058100979 BRIDGE DIODE KBP205
D403 2058100996 DIODE 1N4006
D404 2058100996 DIODE 1N4006
D405 2058100996 DIODE 1N4006
D406 2058100996 DIODE 1N4006
D407 2058100996 DIODE 1N4006
D408 2058100996 DIODE 1N4006
D409 2058502240 ZENER DIODE UZ24BM
D410 2058502240 ZENER DIODE UZ24BM
D411 2058100110 BRIDGE DIODE KBP205
P401 3248347120-T THD BE471TS
F401 5508412734 FUSE 20 mm UL 2 A TS
F402 5508412734 FUSE 20 mm UL 2 A TS
F403 5508412734 FUSE 20 mm UL 2 A TS
F404 5508412734 FUSE 20 mm UL 2 A TS
F405 5508223937 FUSE 31.8 mm UL 10 A NB
FH01 4458999110 FUSE HOLDER FUSE CLIP
FH02 4458999110 FUSE HOLDER FUSE CLIP
FH03 4458999110 FUSE HOLDER FUSE CLIP
FH04 4458999110 FUSE HOLDER FUSE CLIP
FH05 4458999110 FUSE HOLDER FUSE CLIP
FAN1 2099900090-J FAN 90 mm
PT1 2828061000
TRANS POWER 120V Version (UL/CSA)
P.T (120V)
PT1 2828061010
TRANS POWER 220V Version (DOM)
P.T (220V)
PT1 2828061020
TRANS POWER 230V Version (Europe)
P.T (230V)
PT1 2828061030
TRANS POWER 240V Version (Europe)
P.T (240V)
R101 3009271973 RES 1/5W 5% 270
R102 3009473973 RES 1/5W 5% 47K
R103 3009224973 RES 1/5W 5% 220K
POWER SUPPLY
Ref No. Part No. ValueDescription
R104 3009561973 RES 1/5W 5% 560
R105 3009102973 RES 1/5W 5% 1 K
R106 3009123973 RES 1/5W 5% 12K
R107 3009182973 RES 1/5W 5% 1K
R108 3009121973 RES 1/5W 5% 220
R109 3009561973 RES 1/5W 5% 560
R110 3009561973 RES 1/5W 5% 560
R111 3009473973 RES 1/5W 5% 47K
R112 3009473973 RES 1/5W 5% 47K
R113 3009473973 RES 1/5W 5% 47K
R114 3009100973 RES 1/5W 5% 10
R115 3002103953 RES 1/5W 1% 10K
R116 3009000973 RES 1/5W 5% 0
R117 4009100973-J RES 1/4W 5% NFR 10
R118 4009821973-J RES 1/4W 5% NFR 82
R119 3009182973 RES 1/5W 5% 1.8K
R120 3009471973 RES 1/5W 5% 470
R121 4009820973-J RES 1/4W 5% NFR 82
R122 4009100973-J RES 1/4W 5% NFR 10
R123 4009221973-J RES 1/4W 5% NFR 220
R124 4009332973-J RES 1/4W 5% NFR 3.3K
R125 3009563973 RES 1/5W 5% 56K
R126 3009563973 RES 1/5W 5% 56K
R127 4009332973-J RES 1/4W 5% NFR 3.3K
R128 4009221973-J RES 1/4W 5% NFR 220
R129 4009221973-J RES 1/4W 5% NFR 220
R130 4009221973-J RES 1/4W 5% NFR 220
R131 4009221973-J RES 1/4W 5% NFR 220
R132 4009221973-J RES 1/4W 5% NFR 220
R133 4009470073-J RES 1/4W 5% NFR 4.7
R134 4009101973-J RES 1/4W 5% NFR 100
R135 3059478783 RES 5W 0.47
R136 3039100674 RES 5W 0.47
R137 4009101973-J RES 1/4W 5% NFR 100
R138 4009470073-J RES 1/4W 5% NFR 4.7
R139 4009470073-J RES 1/4W 5% NFR 4.7
R140 4009101973-J RES 1/4W 5% NFR 100
R141 3059478783 RES 5W 0.47
R142 3039100674 RES 5W 0.47
R143 4009101973-J RES 1/4W 5% NFR 100
R144 4009470073-J RES 1/4W 5% NFR 4.7
R145 3039100674 RES 3W 10
R146 3039479572-F RES 2W 4.7
R147 3009223973 RES 1/5W 5% 22K
R148 3009223973 RES 1/5W 5% 22K
R149 3009104973 RES 1/5W 5% 100K
R150 3009184973 RES 1/5W 5% 180K
R151 3009104973 RES 1/5W 5% 100K
R152 3009822973 RES 1/5W 5% 8.2K
R153 3009104973 RES 1/5W 5% 100K
R154 3009223973 RES 1/5W 5% 10K
R155 3009223973 RES 1/5W 5% 22K
R156 3009682973 RES 1/5W 5% 6.8K
R157 3009223973 RES 1/5W 5% 22K
R158 3009223973 RES 1/5W 5% 22K
R159 3009223973 RES 1/5W 5% 22K
R160 3009223973 RES 1/5W 5% 22K
R161 3009221973 RES 1/5W 5% 220
R162 3009223973 RES 1/5W 5% 22K
C101 3409547031-T CAP ( AF ) 47UF / 16V
C102 3509471130-T CAP ( CE ) 470P
C103 3609104120-T CAP ( MA) 104 / 100V
C104 3609104120-T CAP ( M ) 104 / 100V
C105 3409810141-T CAP ( E ) NP 100UF / 25V
C106 3509822150-T CAP ( C ) 822P
C107 3509220150-T CAP ( C ) 22P / 500V
C108 3509509060-T CAP ( C ) 5P / 500V
C109 3609222120-T CAP ( M ) 222 / 100V
C110 3609222120-T CAP ( M ) 222 / 100V
C111 3409247991-T CAP ( E ) 4.7UF / 100V
C112 3409247991-T CAP ( E ) 4.7UF / 100V
C113 3529103531-A CAP ( C ) “10,000P”
C114 3609104120-T CAP ( M ) 104 / 100V
C115 3609104120-T CAP ( M ) 104 / 100V
C116 3409222171-T CAP ( E ) 220UF / 50V
C117 3409810141-T CAP ( E ) NP 100UF / 25V
Ref No. Part No. ValueDescription
C118 3409247137-T CAP ( E ) 470UF / 16V
C119 3409247137-T CAP ( E ) 470UF / 16V
C120 3409222171-T CAP ( E ) 220UF / 50V
C121 3409222871-T CAP ( E ) 0.22UF / 50V
D101 2058304100 DIODE 1N4148
D102 2058304100 DIODE 1N4148
D103 2058304100 DIODE 1N4148
D104 2058304100 DIODE 1N4148
D105 2058304100 DIODE 1N4148
D106 2058304100 DIODE 1N4148
D107 2058304100 DIODE 1N4148
D108 2058304100 DIODE 1N4148
D109 2058304100 DIODE 1N4148
D110 2058304100 DIODE 1N4148
D111 2058304100 DIODE 1N4148
D112 2058100110 DIODE PS2010
D113 2058100110 DIODE PS2010
D114 2058304100 DIODE 1N4148
Q101 2008206106-T T . R KTA2400G
Q102 2008206106-T T . R KTA2400G
Q103 2008206106-T T . R KTA2400G
Q104 2008606108-T T . R KTC2240BL
Q105 2008606108-T T . R KTC2240BL
Q106 2008005999 T . R 2SA1546
Q107 2028407990 T . R 2SC4370
Q108 2008405999 T . R 2SC4001
Q109 2008606108-T T . R KTC2240BL
Q110 2008206106-T T . R KTA2400G
Q111 2028407990 T . R 2SC4370
Q112 2008005999 T . R 2SA1546
Q113 2028407122 T . R KTC5200
Q114 2028107118 T . R 2SA1943
Q115 2028407122 T . R KTC5200
Q116 2028107118 T . R 2SA1943
Q117 2008606108-T T . R KTC2240BL
Q118 2008206104-T T . R A1268BL
VR101 3248347120 SEMI 470B
P101 2438007994 POSISTOR BE471TS
P102 2438007993 POSISTOR BE222TS
RY101 3248347120 RELAY
IC101 2118050410 I . C TA7317P
L101 2648099940 COIL 1.2 UH
R201 3009271973 RES 1/5W 5% 270
R202 3009473973 RES 1/5W 5% 47K
R204 3009561973 RES 1/5W 5% 560
R205 3009102973 RES 1/5W 5% 1 K
R206 3009123973 RES 1/5W 5% 12K
R207 3009182973 RES 1/5W 5% 1K
R208 3009121973 RES 1/5W 5% 220
R209 3009561973 RES 1/5W 5% 560
R210 3009561973 RES 1/5W 5% 560
R211 3009473973 RES 1/5W 5% 47K
R212 3009473973 RES 1/5W 5% 47K
R213 3009473973 RES 1/5W 5% 47K
R214 3009100973 RES 1/5W 5% 10
R215 3002103953 RES 1/5W 5% 10K
R216 3009000973 RES 1/5W 5% 0
R217 4009100973-J RES 1/4W 5% NFR 10
R218 4009820973-J RES 1/4W 5% NFR 82
R219 3009182973 RES 1/5W 5% 1.8K
R220 3009471973 RES 1/5W 5% 470
R221 4009820973-J RES 1/4W 5% NFR 82
R222 4009100973-J RES 1/4W 5% NFR 10
R223 4009221973-J RES 1/4W 5% NFR 220
R224 4009332973-J RES 1/4W 5% NFR 3.3K
R225 3009563973 RES 1/5W 5% 56K
R226 3009563973 RES 1/5W 5% 56K
R227 4009221973-J RES 1/4W 5% NFR 3.3K
R228 4009221973-J RES 1/4W 5% NFR 220
R229 4009221973-J RES 1/4W 5% NFR 220
R230 4009221973-J RES 1/4W 5% NFR 220
R231 4009221973-J RES 1/4W 5% NFR 220
R232 4009221973-J RES 1/4W 5% NFR 220
R233 4009470073-J RES 1/4W 5% NFR 4.7
R234 4009101973-J RES 1/4W 5% NFR 100
R235 3059478783 RES 5W 0.47
Ref No. Part No. ValueDescription
R236 3039100674 RES 5W 0.47
R237 4009101973-J RES 1/4W 5% NFR 100
R238 4009470073-J RES 1/4W 5% NFR 4.7
R239 4009470073-J RES 1/4W 5% NFR 4.7
R240 4009101973-J RES 1/4W 5% NFR 100
R241 3059478783 RES 5W 0.47
R242 3039100674 RES 5W 0.47
R243 4009101973-J RES 1/4W 5% NFR 100
R244 4009470073-J RES 1/4W 5% NFR 4.7
R245 3039100674 RES 3W 10
R246 3039479572-F RES 2W 4.7
R247 3009223973 RES 1/5W 5% 22K
R248 3009223973 RES 1/5W 5% 22K
R249 3009223973 RES 1/5W 5% 22K
R250 3009223973 RES 1/5W 5% 22K
R251 3009223973 RES 1/5W 5% 22K
R252 3009223973 RES 1/5W 5% 22K
R253 3009221973 RES 1/5W 5% 220
R254 3009223973 RES 1/5W 5% 22K
R255 3009224973 RES 1/5W 5% 220K
C201 3409547031-T CAP ( E ) 47UF / 16V
C202 3409471231-A CAP ( C ) 470P
C203 3609104120-T CAP ( M) 104 / 100V
C204 3609104120-T CAP ( M ) 104 / 100V
C205 3409810141-T CAP ( E ) NP 100UF / 25V
C206 3509822150-T CAP ( C ) 822P
C207 3509220150-T CAP ( C ) 22P / 500V
C208 3509509060-T CAP ( C ) 5P / 500V
C209 3609222120-T CAP ( M ) 222 / 100V
C210 3609222120-T CAP ( M ) 222 / 100V
C211 3409247991-T CAP ( E ) 4.7UF / 100V
C212 3409247991-T CAP ( E ) 4.7UF / 100V
C213 3509102231-A CAP ( C ) 10,000P
C214 3609104120-T CAP ( M ) 104 / 100V
C215 3609104120-T CAP ( M ) 104 / 100V
C216 3609104120-T CAP ( E ) 0.22UF / 50V
D201 2058304100 DIODE 1N4148
D202 2058304100 DIODE 1N4148
D203 2058304100 DIODE 1N4148
D204 2058304100 DIODE 1N4148
D205 2058304100 DIODE 1N4148
D206 2058304100 DIODE 1N4148
D207 2058304100 DIODE 1N4148
D208 2058304100 DIODE 1N4148
D209 2058304100 DIODE 1N4148
D210 2058304100 DIODE 1N4148
D211 2058304100 DIODE 1N4148
D212 2058100110 DIODE PS2010
D213 2058100110 DIODE PS2010
D214 2058100996 DIODE 1N4006
D215 2058304100 DIODE 1N4148
Q201 2008206106-T T . R KTA2400G
Q202 2008206106-T T . R KTA2400G
Q203 2008206106-T T . R KTA2400G
Q204 2008606108-T T . R KTC2240BL
Q205 2008606108-T T . R KTC2240BL
Q206 2008005999 T . R 2SA1546
Q207 2028407990 T . R 2SC4370
Q208 2008405999 T . R 2SC4001
Q209 2008606108-T T . R KTC2240BL
Q210 2008206106-T T . R KTA2400G
Q211 2028407990 T . R 2SC4370
Q212 2008005999 T . R 2SA1546
Q213 2028407122 T . R KTC5200
Q214 2028107118 T . R 2SA1943
Q215 2028407122 T . R KTC5200
Q216 2028107118 T . R 2SA1943
Q217 2008606108-T T . R KTC2240BL
Q218 2008206104-T T . R A1268BL
VR201 3248347120 SEMI 470B
P201 2438007994 POSISTOR BE471TS
RY201 2438007993 RELAY
L201 2648099940 COIL 1.2 UH
R301 3009271973 RES 1/5W 5% 270
R302 3009473973 RES 1/5W 5% 47K
R303 3009224973 RES 1/5W 5% 220K
8
ELECTRICAL PARTS LIST
POWER AMP
To Next Page
