PAM-60/PAM-120 Public Address Amplifier
Specifications
AMPLIFIER SECTION
Rated Output Power (THD 1%) PAM-60: 60W (RMS)
PAM-120: 120W (RMS)
Frequency Response 80Hz–20kHz
T.H.D (at 1kHz Rated Output) Less than 1%
S/N Better than 100dB
Input Sensitivity/Impedance
CH 1~CH 6 1mV~160mV/600
Link In 100mV/15k
Telephone In 0.775V/600
Amp In 1V/47k
Speaker Output/Impedance
PAM-60 60W(4), 83(70V), 165(100V)
PAM-120 120W(4), 42(70V), 83(100V)
Pre Amp Out/Impedance 1V/600
Music On Hold/Impedance 0.775V/600
Link Out/Impedance 500mV/600
Tone Control (100Hz, 10kHz) ±12dB
EQ Control (100Hz, 1kHz, 10kHz) ±12dB
GENERAL
Power Source AC 110V–240V, 50/60Hz, 24VDC
Power Consumption PAM-60: 150W
PAM-120: 300W
Weight PAM-60: 11.4kg (25.1 lbs.)
PAM-120: 13.5kg (29.7 lbs.)
Dimensions 420 (W) x132 (H) x 360 (D) mm
16.5(W) x 5.2 (H) x 14.2 (D) in
* Specifications and design subject to change without notice for improvements.
