Coil Nailer
Drives Plastic Sheet Nails (1¼" to 2½" / 32 to 65mm)
or Wire Weld Nails (1¾" to 2½" / 45 to 65mm)
Model No. CN565-15
Item No. 65555
18
Interchange Brands Operator’s Manual
PARTS LIST FOR CN565-15
NO. ORDER NO. DESCRIPTION NO. ORDER NO. DESCRIPTION
1 610560 BOLT M6X20 (Loctite 243) 58 330010 TRIGGER VALVE BUSHING
2 320940 BUSHING 59 510180 O-RING 5.8X1.9
3 410280 EXHAUST COVER 60 420640 PIN CAP ©
4 320930 EXHAUST FILTER (A) 61 320800 STEP PIN
5 320920 EXHAUST FILTER (B) 62 620390 FEED SPRING
6 110210 CYLINDER CAP 63 320960 CHECK TOE
7 610230 BOLT M6X30 64 420170 PIN CAP (A)
8 320910 SIDE PROTECTOR 65 210210 FEED PAWL
9 320900 PISTON STOP SEAT 66 320780 FEED PAWL PIN
10 410270 PISTON STOP 67 110220 NOSE
11 320890 WASHER 68 320850 DOOR PIN
12 620380 COMPRESSION SPRING 69 420630 DUST COVER
13 420610 HEAD VALVE PISTON 70 420620 GUARD COVER
14 510710 O-RING 54X3.1 71 210250 DOOR
15 510560 O-RING 41.2X2.65 72 420160 PIN CAP (B)
16 410260 HEAD VALVE SLEEVE 73 210230 CHECK PAWL (A)
17 410250 BUMPER 74 620300 CHECK SPRING (A)
18 520130 CYLINDER SEAL 75 620070 CHECK SPRING (B)
19 511010 O-RING 63.8X3.1 76 210240 CHECK PAWL (B)
20 510680 O-RING 50X2.65 77 320950 CHECK PAWL PIN
21 310180 CYLINDER 78 610110 BOLT M5X22
22 420600 CYLINDER RING 79 210270 LATCH
23 110200 BODY 80 620430 LATCH SPRING
24 640180 ROLL PIN 3X30 81 320990 STEP PIN
25 410460 HANDLE GRIP 82 610320 NUT M5 (Nylock)
26 323220 ROLL PIN 2X8 83 510640 O-RING 47.5X1.8
27 620370 SPRING 84 610220 BOLT M6X25 (Loctite 243)
28 110190 ADJUST BUTTON 85 510260 O-RING 9X1.8
29 320880 CONTACT PLATE 86 620340 SPRING
30 420590 TRIGGER BRACKET 87 320770 FEED PISTON
31 420580 TRIGGER 88 510390 O-RING 17X2.65
32 321810 STEP PIN 89 620420 FEED PISTON SPRING (A)
33 420950 PIN CAP 90 620410 FEED PISTON SPRING (B)
34 510220 O-RING 6.7X1.8 91 410240 FEED PISTON BUMPER
35 321740 SAFETY UPPER 92 320760 FEED PISTON CAP
36 620320 SPRING 93 630080 SNAP RING
37 420560 SAFETY UPPER GUIDE 94 410290 NOSE CAP
38 640020 ROLL PIN 2.5X10 95 110310 END CAP
39 420180 ADJUST DIAL 96 420540 FILTER
40 420650 SAFETY GUIDE 97 630110 SNAP RING
41 323120 SAFETY 98 420240 SPRING HOLDER (B)
42 320980 DRIVE BLADE (Loctite 262) 99 421570 MAGAZINE
43 310190 PISTON 100 610130 BOLT M5X30
44 510510 O-RING 37.5X3.55 101 321890 WASHER
45 620910 SNAP RING 102 320260 MAGAZINE PIN
46 510140 O-RING 5.15X1.8 103 620650 MAGAZINE SPRING
47 320970 ADJUSTER 104 420210 NAIL SUPPORT PLATE
48 640250 STRAIGHT PIN B3X15 105 420520 SPRING HOLDER (A)
49 510410 O-RING 18.3X2.65 106 420530 MAGAZINE COVER
50 420090 TRIGGER VALVE CAGE 107 620740 SPRING
51 510380 O-RING 16X1.8 108 520290 GASKET
52 420080 TIGGER VALVE CAP 109 323130 STRAIGHT PIN
53 320110 TIGGER STEM 110 410880 STRAIGHT PIN CAP
54 510030 O-RING 2.5X1.4 111 410060 RUBBER BUTTON
55 620050 SPRING
56 510240 O-RING 8.6X1.9 P1 D320981 DRIVER UNIT
57 510210 O-RING 6.3X1.8 P2 T420091 TRIGGER VALVE
