Coil Nailer
Drives Plastic Sheet Nails (1¼" to 2½" / 32 to 65mm)
or Wire Weld Nails (1¾" to 2½" / 45 to 65mm)
Model No. CN565-15
Item No. 65555
5
Interchange Brands Operator’s Manual
Parts Identification
➊ Casting
➋ Cylinder Cap
➌ Safety
➍ Guide Body
➎ Magazine
➏ Trigger
➐ Grip
➑ Exhaust Cover
TOOL AIR FITTINGS: This tool uses a minimum 1/4" N.P.T. male plug. The inside
diameter should be 0.28" ﹙7mm﹚ or larger. The fitting must be capable of discharging
tool air pressure when disconnected from the air supply.
RECOMMENDED OPERATING PRESSURE:
70 to 120 psi / 5 to 8.5 kgs.
Select the operating air pressure within this range for best fastener performance.
Accessories
STANDARD ACCESSORIES
1 Eye Protection 1
①
➊
➋
➌
➍
➎
➏
➐
➑
