7 Maintenance
7.1 Maintenance Schedule
Action
Frequency
Date
Date
Date
Control of cables and connectors
1x p.a.
Calibration
< 26 months
Control of fixation (flanges, shafts)
1x p.a.
7.2 Trouble Shooting
This chart is used for searching for the most frequent errors and their elimination.
Problem
Possible Cause
Trouble Shooting
No signal
No sensor excitation
 Outside of permissible range
 Connect excitation
 Cable defect
 No mains supply
Signal output connected wrong
 Connect output correctly
 Evaluation electronics defect
Sensor does not react to
torque
Shaft not clamped
 Clamp correctly
No power supply
 Outside of permissible range
 Connect supply
 Cable defect
 No mains supply
Cable defect
 Repair cable
Connector connected wrong
 Connect correctly
Signal has dropouts
Cable defect
 Repair cable
Zero point outside of tolerance
Cable defect
 Repair cable
Shaft mounted distorted
 Mount correctly
Distorted shaft string
 Release from distortion
Strong lateral forces
 Reduce lateral forces
Shaft overloaded
 Send to manufacturer
Wrong torque indication
Calibration not correct
 Re-calibrate
Sensor defect
 Repair by manufacturer
Torque shunt
 Eliminate shunt
8 Decommission
 All sensors must be dismantled professionally.
 Do not strike sensor housings with tools.
 Do not apply bending moments on the sensor, e.g. through levers.
 The torque sensor must be supported to avoid falling down during the dismantling.
9 Transportation and Storage
The transportation of the sensors must occur in suitable packing.
For smaller sensors, stable cartons which are well padded are sufficient (e.g., air cushion film, epoxy
crisps, paper shavings). The sensor should be tidily packed into film.
Larger sensors should be packed in cases.
9.1 Transportation
Only release well packed sensors for transportation. The sensor should not be able to move back and
forth in the packing. The sensors must be protected from moisture.
Only use suitable means of transportation.
