Intergas Combi Compact HRE 24/18 User Manual

Intergas Heating Ltd 7
2.4 Technical data
Appliance category C13; C33; C43; C53; C83
Gas supply pressure 20 mbar -G20 ; 37 mbar – G31
Gas Category II2H3P
Technical data Combi Compact HRE 24/18 28/24 36/30 36/40
Gas Council number G.C. 47-291-01 G.C. 47-291-02 G.C. 47-291-03 G.C. 47-291-04
DHW
Input kW 5.6 – 22.1 7.1 – 28.0 7.6 – 32.7 7.8 – 32.7
DHW threshold l/min 2 2 2 2
DHW Flow Rate at 40°C l/min 10 12.5 15 15
DHW Flow Rate at 60°C l/min 6 7.5 9 9
∆T 25 °C
l/min 12 15 18 18
∆T 35 °C
l/min 8.5 10,5 13 13
DHW temperature (factory setting) °C 55 55 55 55
Max. DHW water pressure bar 8 8 8 8
DHW side pressure loss KPa See § 8.2.2 See § 8.2.2 See § 8.2.2 See § 8.2.2
CH
Nom. Input rating (lower value)* kW 5.6 – 18.7 7.1 – 23.7 7.6 – 27.0 7.8 – 42.5
Rated power* kW 6.1 – 18.2 7.7 – 23.1 8.2 – 26.6 8.3 - 40.9
Max. CH water pressure bar 2.5 2.5 2.5 2.5
Max. CH water temperature °C 90 90 90 90
Other data
Gas consumption (G20) m
3
/h 0.58 – 2.29 0.75 – 2.91 0.79 – 3.39 0.80 – 4.41
Gas consumption (G31) m
3
/h 0.22 – 0.87 0.28 – 1.11 0.30 – 1.29 0.31 –1.68
Appliance pressure loss (CH) mWk See § 10.5 See § 10.5 See § 10.5 See § 10.5
NOx class natural gas 5 5 5 5
NOx class LPG 5 4 5 5
Electrical data
Mains power V 230 230 230 230
Safety class IP IP44 IP44 IP44 IP44
Power consumption : full load W 80 80 80 135
Power consumption: standby W 2 2 2 2
Boiler dimensions and weight
Height mm 590 650 710 710
Width mm 450 450 450 450
Depth mm 240 240 240 240
Weight kg 30 33 36 36
(*) The maximum CH power is factory set at 70% of the highest value (See section §10.4, Setting maximum CH power).
We have a policy for continual improvement and development, therefore we reserve the right to change specifications without prior notice.

Intergas Combi Compact HRE 24/18 Specifications

General

Model	Combi Compact HRE 24/18
Category	Boiler
Efficiency	93%
Weight	32 kg
Boiler Type	Combi
Mounting	Wall Mounted
ERP Rating	A
Max. working pressure	3 bar
Fuel	Natural Gas
Efficiency (%)	93
