Intergas Combi Compact HRE 28/24 User Manual

Intergas Heating Ltd 6
2 SAFETY REGULATIONS
The manufacturer Intergas Heating Ltd accepts no liability whatsoever for damage or injury caused
by failure to adhere (strictly) to the safety regulations and instructions, or carelessness during
installation of the Intergas Combi Compact HRE High Efficiency wall mounted gas fired boiler and
any associated accessories.
2.1 General
It is law that all gas appliances are installed by a Gas Safe registered competent engineer and in
accordance with the following recommendations:
• Current Gas Safety (Installation and Use) Regulations
• All current building regulations
• Building Standards (Scotland) Consolidated
• This appliance must be installed in accordance with the Gas (Safety and Use) Regulations,
current Building Regulations, Building Standards (Scotland), I.S.813 Installation of Gas
Appliances (Ireland), IEE Wiring Regulations (BS 7671), Health and Safety Document No. 635
(Electricity at Work Regulations) and Local Water Authority Bye Laws
• UK Water Regulations and Bye Laws
• Health & Safety
2.2 The Installation
The installation must comply with the following British Standards codes of practice:
• BS 5440: Flues and Ventilation for gas appliances of rated input not exceeding 70kW (Part 1
Flues)
• BS 5440: Flues and Ventilation for gas appliances of rated input not exceeding 70kW (Part 2 Air
Supply)
• BS 5546: 2000 Installation of gas hot water supplies for domestic purposes.
• BS 5549: 1990 Forced circulation hot water systems
• BS 6700: 1997 Design, Installation, testing and maintenance of services supplying hot water
• BS 6798: 2000 Specification for installation of gas fired hot water boilers of rated input not
exceeding 70kW
• BS 6891: 1998 Installation of low pressure gas pipe-work installations up to 35mm (RI)
• BS 7593: 1992 Code of practice for treatment of water in heating systems
• BS 7671: 2001 Requirements for electrical installations, IEE Wiring regulations
Reference should also be made to:
• Guide to condensing boiler installation assessment procedures for dwellings
• The institute of Gas Engineers document IGE/UP/7 for timber frame dwellings
2.3 Approvals
Natural Gas
Intergas Combi Compact HRE Pre-mix Condensing Combination Boiler
British Gas Service Listing:
Combi Compact HRE 36/40 G.C.N. 47-291-04
Combi Compact HRE 36/30 G.C.N. 47-291-03
Combi Compact HRE 28/24 G.C.N. 47-291-02
Combi Compact HRE 24/18 G.C.N. 47-291-01
Notified /Body
The Intergas Combi Compact HRE range of central heating boilers are manufactured from high
quality materials and designed for reliability and optimum performance.
Intergas is committed to the continual development of their appliances and reserves the right to
make changes without notification to ensure their customers benefit from the latest advances in combustion technology and energy conservation.
Gastec 0063BT3576 Directive 90/396/EEC
Directive 92/42/EEC

Intergas Combi Compact HRE 28/24 Specifications

General

Type	-
Fuel type	Natural gas
Boiler system	Combi boiler system
Product color	White
Heater location	Indoor
Placement supported	Vertical
Gas inspection label	CW, HRe, NZ, SV
Boiler type (NL label)	HR
CW inspection label class	4
HR inspection label class	107
Efficiency	107 %
Maximum power	- W
Water flow (40 °C)	12.5 l/min
Water flow (60 °C)	7.5 l/min
Maximum operating pressure	3 bar
Domestic Hot Water (DHW) flow	- l/min

Weight and Dimensions

Depth	240 mm
Width	450 mm
Height	650 mm
Weight	33000 g
