6 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
(15)
 / Down
Scroll down in the menus
Change value
Backspace
(16)
Alphanumeric keys
Keys 1 to 9, alphanumerical data. See “Keypad layout” on page 40.
(17)
Menu
Request entry to the menus
(18)
Enter
Complete the step
Enter the selected menu entry
(19)
0
Key 0
Toggle selection
(20)
Area LEDs 1 to 16
On: area set
Off: area unset
Flashing: area alarm condition
(21)
Partset 1
Part set 1 of areas
(22)
Partset 2
Part set 2 of areas
(23)
A, B, C
Programmable function keys
(24)
LED1
Programmable LED 1
(25)
LED2
Programmable LED 2
Figure 10: ATS1190/ATS1192 readers
Figure 11: ATS1197 reader with keypad
Figure 12: ATS1151/ATS1156 readers
(1)
(2)
OFF ON
(3)
(4)
(5)
(6)
(7)
(8)
1 2 3
4 5 6
7 8 9
*
0 #
(4) (5) (6)
(7) (8)
(3)
1 2 3
4 5 6
7 8 9
*
0 #
(3) (4) (5) (6)
(7) (8)
