Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 153
8.5.3 Siren tamper EOL
The Siren tamper end of line resistor menu allows you to define an end-of-line
resistor value for the siren. The available values are the same as in “8.5.2 EOL”
on page 152.
8.5.4 Swinger shunt
The Swinger shunt value defines the number of alarms from a zone until it is
shunted. The default value is 2, the maximum number is 4.
This zone must have the “4.1.n.6.5 Swinger shunt” option enabled (see page 98).
8.5.5 Report restore
If the Report restore option is set to On ACK, the restore event is reported to the
central station when a user acknowledges an alarm.
If the option is set to On input close, the restore event is reported when the zone
returns to the normal state.
Part set options
8.6 Part set
The Part set menu allows you to configure the part set options.
8.6.1 Report BA
If the Report BA option is set to Yes, in the part set the system reports burglar
alarms triggered during part set to the central station.
8.6.2 Access to EE
If the Access to EE option is set to Yes, Access zones become Entry/Exit zones
during part set. Users being inside the premises will then trigger the entry timer
making them aware that the area is set and an unset procedure is required.
