Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 59
• Stopped: GPRS functionality is available, but connection is stopped due to
the disconnection time expiration. See “9.3.n.7.8 Disconn.time” on page 185
for more details.
• No data: Unknown error.
1.2.8.6 Network name
6>Network name
MyGSM
Network name is the name of the GSM network that the GSM dialler is currently
registered in. This is read-only information. The name can be “unknown”, if the
network code is not recognized by the communication module.
1.2.8.7 Network code
7>Network code
The network code is the unique identification number of the GSM network in
which the GSM dialler is currently registered.
1.2.8.8 RSSI
8>RSSI
23 [IIII ]
The Received Signal Strength Indication (RSSI) value is read-only diagnostic
information.
The following ranges are available.
Table 19: RSSI ranges
RSSI
Signal level
Bar indicator
Description
0
<−112 dBm
[ ]
No signal
1 to 7
−111 to −99 dBm
[I ]
Insufficient signal
8 to 12
−97 to −89 dBm
[II ]
Mediocre signal
13 to 20
−87 to −73 dBm
[III ]
Good signal
21 to 26
−71 to −61 dBm
[IIII ]
Excellent signal
27 to 31
>−60 dBm
[IIIII]
Excellent signal
For accurate data transfer, we recommend a RSSI value above 16.
1.2.8.9 Msg sent 24h
1>All SMSes
0
The Msg sent 24h menu lists the SMS messages sent since midnight (00:00).
The following submenus are available.
