Concord 4 User Manual 7
LEDs
Some touchpads have two LEDs that indicate the current system status at a
glance. The red LED is labeled Armed; the green LED is labeled Ready. Table 2
below explains LED behavior.
Table 2: Status LEDs
System status
Red armed LED
Green ready LED
Exit delay
Flashing
Armed to Level 1 (off)
Off
On
Armed to Level 2 (stay) or Level 3 (away)
On
Entry delay
Flashing
Off
System trouble (check system status) protest
Off
System OK
On
