6
P/N 466-5308 • REV A • ISS 09MAY17 ©2017 United Technologies Corporation
3. Other Detector Visual and Audible Indicators
Operational Mode Visual Indications Audible Indications Action/Note:
Normal Operation
(standby)
One GREEN LED blink
every 60 seconds.
Freeze Warning One RED LED blink
every 20 seconds.
None None. Flashing continues
while condition exists.
Tamper Condition One RED LED blink
every 30 seconds
(after a 3 minute
delay).
Detector chirps once when tamper
condition is rst sensed, then the
detector will chirp every 30 seconds
after a 3 minute delay.
Reattach detector to its trim
plate, otherwise ashing and
chirping will continue while
condition exists.
System Test Mode Rapidly ashing RED
LED for 10 seconds
duration
1 detector chirp when magnet
detected, 2 detector chirps when System
Test mode enabled
Hold magnet next to button
for 4 seconds. See Figure 5.
Local Detector Test
(button press when
no alarm condition
is present)
Flashes RED, AMBER,
GREEN, then current
protocol
Temporal T3 pattern Allow completion of test or
perform button press to
cancel, return to normal
operation
System Detector Test
(button press in System
Test Mode when no
alarm condition is
present)
Flashes RED, AMBER,
GREEN, then current
protocol on each
detector in the network
Temporal T3 pattern Allow completion of test or
perform button press to
cancel, return to normal
operation.

Interlogix SDX-135Z Specifications

General

Bandwidth	319.5 MHz
Detector type	Photoelectrical reflection detector
Mounting type	Surface-mounted
Product color	White
Interconnectable	Yes
Connectivity technology	Wireless
Battery life	10 year(s)
Battery type	Built-in battery
Power source	Battery
Battery voltage	3 V
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 37.8 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Height	55.6 mm
Diameter	142.3 mm
