: KTD-405 keypad
TruVision DVR 12HD User Manual 149
Camera
input
Zone ID of TVR 12
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
21
20 52 84 116 148 180 212 244 276 308 340 372 404 436 468 500
22
21 53 85 117 149 181 213 245 277 309 341 373 405 437 469 501
23
22 54 86 118 150 182 214 246 278 310 342 374 406 438 470 502
24
23 55 87 119 151 183 215 247 279 311 343 375 407 439 471 503
25
24 56 88 120 152 184 216 248 280 312 344 376 408 440 472 504
26
25 57 89 121 153 185 217 249 281 313 345 377 409 441 473 505
27
26 58 90 122 154 186 218 250 282 314 346 378 410 442 474 506
28
27 59 91 123 155 187 219 251 283 315 347 379 411 443 475 507
29
28 60 92 124 156 188 220 252 284 316 348 380 412 444 476 508
30
29 61 93 125 157 189 221 253 285 317 349 381 413 445 477 509
31
30 62 94 126 158 190 222 254 286 318 350 382 414 446 478 510
32
31 63 95 127 159 191 223 255 287 319 351 383 415 447 479 511
Connecting a KTD-405 keypad and dome camera
to the recorder
Use the input/output box that is supplied with the keypad to connect the KTD-405
keypad to the recorder.
As the KTD-405 keypad uses full duplex data communication, you cannot connect the
both keypad and a dome camera directly to the recorder from the RS-485 port as this
could cause problems on the bus. If both devices are required, it is recommended that
you use the keypad’s RS-422 connection to connect the dome camera and the
keypad’s RS-485 connection to connect the recorder. See Figure 38 as well as
Table 24 and Table 25 below.
Note: These connections only work with UTC PTZ protocols (see Appendix B “PTZ
protocols” on page 135). If you are using another manufacturer’s PTZ protocol, it is not
possible to connect both a keypad and dome camera to the recorder.
