EasyCoder 201 II – Installation Instructions
1
This booklet contains instructions on how to install the Label-
Taken Sensor Kit (LTS) on an EasyCoder 201 II printer. Installa-
tion should preferably be performed by an authorized service
technician.
For instructions on how to use the label-taken sensor, please refer
to the EasyCoder 201 II Technical Manual.
The Label-Taken Sensor kit consists of:
• 1 Reflecting Sensor assy. with bracket and cable
• 1 Screw
• This Installation Instructions booklet.
The status of the LTS has to be polled in the Intermec Fingerprint
program by means of the PRSTAT function, as otherwise the printer
will not react on the LTS signal.
❑ Make a simple program that checks the printer's status, e.g.:
10 BREAK 1,88
20 BREAK 1 ON
30 FORMFEED
40 IF (PRSTAT AND 2) THEN BEEP
50 GOT0 40
60 END
RUN
You can break this program by transmitting the character X
(ASCII 88) decimal on the standard serial interface "uart1:".
LABEL-TAKEN SENSOR KIT
General Information
Preparation Before
Installation
Information in this manual is subject to change without prior notice and does not
represent a commitment on the part of Intermec Printer AB.
© Copyright Intermec PTC AB, 1998. All rights reserved. Published in Sweden.
EasyCoder and Fingerprint are registered trademarks of Intermec Technolo-
gies Corp.
EasyCoder 201 II
Label-Taken Sensor Kit
Installation Instructions
Edition 3, September 1998
Part No. 1-960255-04
