20
Printing a Test Label to Test Communications
If you would like to test your communications by downloading a label, follow the example below.
Use the PrintSet application software to send a test label to the printer.
To print a test label
1. Start PrintSet on your PC.
2. Click the Test Print button.
3. Select the Test Label option button.
4. Select either the Text or the Bar Code option button.
• If you select to print text, you can choose a font in the Select Printer Font list box.
• If you select to print a bar code, you can choose a symbology in the Select Symbologies list
box.
5. Click on the Print button. Your 4420 or 4440 printer prints out your selected test label.
For example, if you choose to print a bar code with the Code 39 symbology, your printer will
print out a label similar to this one:
1234567
*0123456789*
¥ *0123456789*
*0123456789*
*0123456789*
44XXG.020
