EasyCoder PC4/PC41 Mobile Battery Unit Installation Instructions 9
Chapter 2 — Operation
Using the Charger (accessory)
To charge an empty battery pack in the charger, proceed as follows:
1 Plug in the power supply adapter.
2 Insert the empty battery pack.
3 Switch on the power using the on/off switch at the rear of the charger.
4 During charging, the charging indictor on the charger unit is amber.
5 When the charging indicator turns green, the battery is fully
recharged. Charging time at room temperature is approximately 2
hours.
6 Possible charging faults are indicated by the charging indicator switch-
ing to blinking amber.
 e battery pack contains nickel/metal hydride (NiMH)
cells which are potentially dangerous to the environment.
Check and follow local regulations for disposal of nickel/
metal hydride batteries. Do not disassemble the battery
pack and only recharge it with approved equipment from
Intermec.
Power supply adapter
Battery
pack
Charger
Charging indicator
on front panel
On/Off switch

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
