Intermec EasyCoder PM4i Installation Instructions

2 Serial/Industrial Interface Kit Installation Instructions
Chapter 1 — Introduction
Description
 is Installation Instructions booklet describes how to install a Serial/
Industrial interface board in an EasyCoder PF2i, PF4i, PF4i Compact
Industrial, PM4i, PX4i, or PX6i printer.
 e installation instructions describes how to physically install the
interface board in a printer and how to confi gure the two serial commu-
nication ports.
 is interface kit must only be physically installed by an
authorized service technician. Intermec assumes no respon-
sibility for personal injury or damage to the equipment if
the installation in performed by an unauthorized person.
Printer Firmware
 e printer must be fi tted with Intermec Fingerprint v8.00 (or later).
For some combinations of two interface boards in EasyCoder PM4i and
PX4/6i printers, Fingerprint v8.30 (or later) is required.  is kit does not
work with IPL. In Intermec Fingerprint, the serial ports are addressed as
"uart2:", "uart3:", "uart4:", and "uart5:" (communication channel #2,
#3, #7, and #8 respectively).
Installation Kit
 e Serial/Industrial Interface Kit contains:
• One Serial/Industrial interface board fi tted with circuits and straps for
RS-232 non-isolated.
• One hexagonal spacer (only used for two interface boards fi tted in a
PM4i or PX4/6i printer)
• Two fl at cables
•  is Installation Instruction booklet
 e only tools required for the installation are #T10 and #T20 Torx
screwdrivers plus a small wrench.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
