Intermec EasyCoder PM4i Installation Instructions

Serial/Industrial Interface Kit Installation Instructions 19
3
Serial Interface "uart2:",
"uart3:", and "uart4:"
 is chapter describes how to modify the interface
board for RS-232 non-isolated (standard), RS-422
isolated/full duplex, or RS-485 isolated/half duplex
on the "uart2:", "uart3:", or "uart4:" port and
explains the confi guration of the interface connector.
When fi tting driver circuit and straps
before installing the interface board,
make sure that the circuit is not fi tted
upside down (see front end markings in
the illustrations). Also make sure that the
“legs” of the circuit fi t into the slots in
the socket and are not bent. Take ample
precautions to protect the board and cir-
cuits from electrostatic discharges.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
