Intermec SF51 Quick Start Guide

5
To connect to an Intermec computer
1 On your PC, start EasySet. Make sure that SF51 is selected as
your product.
2 From the EasySet commands window, select Data
transmission settings > Bluetooth Parameters > connect/
disconnect.
3 Double-click compose BT address.
4 Enter the Bluetooth address of your Intermec computer and
click OK. The bar code appears on the setup sheet.
5 Scan the bar code onscreen with the SF51, or print the bar
code setup sheet and scan the bar code. The SF51 beeps once,
the green status light flashes once, and the blue Intermec
Ready-to-Work™ indicator starts blinking.
When the SF51 connects to your Intermec computer, the
SF51 emits a series of beeps from low to high, and the blue
Intermec Ready-to-Work indicator turns on. The SF51 is
ready to scan data.
To connect to a PC with the USB Bluetooth adapter
1 Install the USB Bluetooth adapter (P/N 203-771-xxx).
2 Connect and pair your SF51 to your host PC.
For more information, see the USB Bluetooth Adapter
Instructions (P/N 074479) that ship with the adapter.
Note: You can also use the Bluetooth Device Utility
or the Bluetooth control panel on your Intermec
computer. For help, see the documentation for your
Intermec computer.
Bluetooth
address

Intermec SF51 Specifications

Capacity and Output

maximum output voltage	4.1 V
mean output voltage	3.7 V
capacity	2400 mAh

Temperature and Humidity

operating temperature range	-20°C to 50°C
charging temperature range	0°C to 35°C
storage temperature range	-20°C to 60°C
recommended storage temperature	21°C
humidity range	0 to 95% non-condensing

Weight and Dimensions

length	73 mm
diameter	19 mm
weight	55 g
