TRAKKER Antares 2420 and 2425 Hand-Held Terminal User’s Manual
Co de 39
Nugget
4-8
You can install the T2425s and access points in your Intermec TCP/IP network as shown
in the illustration below. The T2425s may only communicate with the access points that
are in the same IP subnetwork. All the terminals and access points in this illustration
communicate with the host at IP address 192.9.175.7 using TCP/IP for the RF protocol.
Installing T2425s in Multiple Subnetworks (TCP/IP)
Access point
Access point
Access point
Router
Ethernet
Host
192.9.200.X
subnetwork
192.9.175.X
subnetwork
TRAKKER Antares
2425 terminals
192.9.175.10
192.9.175.11
192.9.175.12
T2425's cannot roam between subnetworks
242XU.169
TRAKKER Antares 2425 terminals
192.9.200.5, 192.9.200.6
192.9.175.7
