Test Equipment for HI with 2 Pin rec
Instrument xture
p/n 17850700 (incl test rec)
Coupler Insert (brass) to be attached
2cc coupler during nal HI test
p/n 16169300
(shown from both sides)
Batt pill size 312
p/n 17449300
must be used
during test
Test frame p/n 16902800
Test Rec (NP)
p/n 17460000 for HI testing
CS44 Prog cable
(Left blue is shown)
9022 907 69019 (R)
9022 907 69029 (L)
2cc coupler
p/n 30-4838800
to be ordered with GTO
Dept/HQ Ballerup DK
Prog adaptor clip
17736900 Red
17736901 Blue
Prog adaptor
p/n 18041400
(incl 1 x red & 1 x blue clip)
P/n 17517800
Prog cable ext must be used during
HI test due to current measurement
(not needed when using tting SW)
P/n 17292000
Airlink to be used for
wireless “Connection test”
Both airlinks can be used for wl
connection test
17292002 AIRLINK 2
Coupler mic,TM-12 measured
p/n 18220700
