Disassemble Procedure - CRISP & SHARE
Unlock the rec by lifting up the conn lock using the mandrel. Push out the pin with a pin removal
tool and pull it out using a tweezer. The conn lock will then fall out without being damaged
Open batt door and pull out
the module
Gently separate the BOT HSG from TOP HSG
Push out the batt door pin
Service module/ASM frame
The soft silicone cap for toggle
must be correct in place before
assembling new HSG parts
Remove TGL by sliding it
