Prog Adaptor Clip
To remove the clip rmly grip this side of prog adapt Pull tip of the clip Slide the clip from adaptor
It is important to have the programming cable connected before adding the clip to the programming adaptor.
Add the clip as shown in the pics. The clip is recommended to be used during test / tting in order to keep the
prog cable connected during the complete procedure
Clip for prog adaptor L/R
