Mechanical installation4
j | BA 14.0168 | 10/2013
30
9
1.1
10
c
KL458-012A
Fig. 8 Torque setting
7 Stator 9 Sleeve bolt { s
LN
10 Cheese head screw
1. Check the air gap near the screws (10) by means of a feeler gauge a nd compare the
values to the values for ”s
LN
” in the table ( 15).
Note!
Do not insert feeler gauge more than 10 mm between armature plate (2) and
stator (1.1)!
H
J
9
1
10
KL458-013A
Fig. 9 Adjusting the air gap
1 Complete stator 10 Cheese head screw
9 Sleeve bolt
If the measured value ”s
L
” is outside the tolerance of ”s
LN
”, set the dimension:
