INTORQ BFK-458-12E - Page 37

Electrical installation5
i
j | BA 14.0168 | 10/2013
37
KL-BFKXXX-003.iso
Fig. 17 With microswitch (release check); connection diagram also valid for star connection
 DC voltage depending on coil voltage  Spark suppressor
KL-BFKXXX-004.iso
Fig. 18 With microswitch / wear check addition for all circuits; connection diagram also valid for star
connection
