5.2.1 Assignment: Bridge/half-wave rectifier - brake size
Rectifier type
AC voltage
Overexcitation Holding current reduction
Coil voltage Size Coil voltage Size
[V AC] [V DC] [V DC]
BEG-561-255-030
230
103
06 ... 16
205
06 ... 14
BEG-561-255-130 ----- 16
BEG-561-440-030-1 400 180 06 ... 16 ----- -----
Fig. 19 BEG-561 attachment features
5.2.2 Technical data
Rectifier type Bridge/half-wave rectifier
Output voltage for bridge rectification 0.9 x U
1
Output voltage for half-wave rectification 0.45 x U
1
Ambient temperature (storage/operation) [°C] -25 ... +70
Type Input voltage U
1
(40 Hz ... 60 Hz)
Max. current I
max.
Overexcitation time t
ue
( ±20%)
min.
[V ∼ ]
rated
[V ∼ ]
max.
[V ∼ ]
bridge
[A]
half-wave
[A]
with U
1min
[s]
with U
1
rated
[s]
with U
1
max
[s]
BEG-561-255-030
160
230 255 3.0 1.5
0.430 0.300 0.270
BEG-561-255-130 1.870 1.300 1.170
BEG-561-440-030-1
230
400 440
1.5 0.75 0.500 0.300 0.270
BEG-561-440-130 3.0 1.5 2.300 1.300 1.200
Input voltage U
1
(40 ... 60 Hz)
Tab. 8 Data for bridge/half-wave rectifier type BEG-561
