Electrical installation5
j | BA 14.0168 | 10/2013
40
5.2.3 Reduced switch-off times
When switching on the DC side (fast engagement), switching on the AC side is also required!
Otherwise, there will be no overexcitation during power-on.
Delayed engagement Fast engagement
1234 65
12 34 65
Mains Bridge Coil
5.2.4 Permissible c urrent load - ambient temperature
BFKXXX-008.iso
1 For screw assembly with metal surface (good heat dissipation)
2 For other assembly (e.g. glue)
