DEPTH LIMITS FOR VISE INSERTS
INSERT NUMBER OFFSET FROM TRUE 0 RANGE OF DEPTHS
1 0.000 INCHES 0.465 - 0.180 INCHES
2 0.035 INCHES 0.430 - 0.145 INCHES
3 0.070 INCHES 0.395 - 0.110 INCHES
4 0.100 INCHES 0.365 - 0.080 INCHES
EXTENDED TABLE
Press the ITL950C now displays EXTENDED TABLE Y/N Press to toggle.
The table must be set to (Y) for keys requiring 11 or 12 spaces.
When you select the extended table function, the ID # following the one you are currently
editing will contain the extra spaces. For example if you were editing ID 803, and selected the
extended table function, ID 804 would contain the 2 extra spaces. Note: You should not use ID
804 as a valid ID. When using the extended table use the maximum space value in the first
table, in this case 803 should be set to 10 and all 10 spaces must be valid. Edi t the second ID in
this case 804 as with any other custom ID however you need enter only spaces 1 and 2. Space
1 would be the 11th space in an extended ID and space 2 would the 12th space.
MAXIMUM SPACE
Press the ITL950C now displays MAXIMUM SPACE. The range is 1 to 10. To select a
maximum space number of 7, press followed by . The display will now show
MAXIMUM SPACE 7. The maximum space number is used to verify correct table set-up, define
table limits and determine code length. Enter and for 10
th
space, not the key.
MAXIMUM DEPTH
Press , the ITL950C now displays MAXIMUM DEPTH. The range is 0 to 10 (not the
key!). To select a maximum depth number of 8, press followed by . The display
will now show MAXIMUM DEPTH 8.
The maximum depth number is used to verify correct table set-up, and define table limits.
MINIMUM DEPTH
Press the ITL950C now displays MINIMUM DEPTH. The range is 0 to 9. To select a
minimum depth number of 1, press followed by . The display now shows MINIMUM
DEPTH 1. The minimum depth number is used to verify correct table set-up, and define table
