8
SETTING DEFAULT MANUFACTURER ID
The default or power on ID is the MFG ID number the machine selects when reset or turned
on. As with any ID, it must be in the range of 1 through 960, and the table must be correct. It can be set
by you and remains set until you select a different ID.
1) Press the keys to enter the EDIT mode. The display will show
EDIT.
2) Press the key to display the current default ID. To change the ID to 23, press
followed by . The ITL950C will display DEFAULT ID 23.
3) Press the key to return to the EDIT mode. Press the key and follow display
comands and the new ID will be displayed when the ITL950C completes the self-test sequence.
SETTING THE BAUD RATE
See page 14 for table and instructions.
UNITS (INCHES – METRIC)
Press and the key three times and the display will read
UNITS = INCHES. To read the display in metric, press the key. Press the key twice
and follow display instructions.
SETTING DEFAULT CUT RATE
The default cut rate is a number from 1 through 4 that defines how fast the blank is fed into
the cutter. 1 is the fastest rate and should work for most blanks however if the cutter becomes
dull or thick blanks are used, you may need to select a slower speed. Proceed as follows to set
the default cut rate. Press to enter the EDIT mode. Press four
times to display CUT FEED RATE(current feed rate).To change the rate to 2, press
The machine will now display CUT FEED RATE 2. Press and . Follow display
instructions and all plunge cuts will be made at cut rate 2.
SETTING DISPLAY MODE
Press to enter the EDIT mode. Press five times to display
BAR GRAPH DISPLAY MODE SELECTED or NUMERIC DISPLAY MODE SELECTED. Press
key to toggle. Press the key twice and follow display instructions.
