7
TEMPORARY CHANGE TO LASER CUT MODE
In the laser cut mode cuts are made from flat edge to flat
edge without the normal inbetween cut points. From the
ready prompt push the C.F. key three times, the display will
read normal cut mode. Push the (-) key to toggle to the laser cut mode and back to the normal
cut mode.
HALF DEPTH MODE
4. Press four times. The ITL950C will now display HALF-DEPTH = NO This is the normal
mode. Push to switch to the half depth mode and all cuts will be made half way to the next
depth. When cutting the key the second line will read < 1/2 Depth = on >.
PLUNGE CUT MODE
5. Press five times. The ITL950C will now display PLUNGE = NONE (Normal cut method)
PLUNGE = ALL (for keys that require straight in and out movement of the cutter) Safety deposit or
flat steel. PLUNGE = FIRST (for keys that require a vertical entry in the first position to avoid cutting
the key shoulder). Press key to toggle to required function, press to return to READY.
CHANGING CUT RATE
6. The cut rate is a number from 1 through 4 that defines how fast a blank is fed into the cutter. 1 is the
fastest rate and should work for most blanks. However if the cutter becomes dull or thick—blanks are
used you may need to select a slower speed. To select a cut rate of 3, proceed as follows. Press the
key 6 times. The display will now read CUT FEED RATE (current rate) press and
, the display will now read CUT FEED RATE 3. Press to return to READY.
BYPASS HOME MODE
7. Press seven times. The ITL950C will now display BYPASS HOME = NO This will
reset the space calibration after every cut. Press the key to toggle to BYPASS HOME =
YES this will temporarily turn off the space calibration. This can be used for impressioning locks
faster. Press to return to READY.
UNITS (METRIC OR INCHES)
8. Press eight times. The ITL950C will now display UNITS (INCHES OR METRIC).
Press key to toggle.
CUSTOM EDIT MODE
Custom default entries using the key remain in memory when the machine is reset or
turned off.
