SECTION 7—SEAT
Part No. 1118395 39 Zoom
300 and Zoom
400
FIGURE 7.5 - REMOVING/INSTALLING SEAT POSITIONING STRAP
Seat Positioning Strap
Washer
Mounting Screw
Seat Positioning Strap
Washer
Mounting Screw
Arm Frame
