2 OVERVIEW
Part No 1123842 7 Invacare
®
IVC
™
Model BAR600IVC Bariatric Bed
2 Overview
2.1 Label locations
! WARNING !
Grounding reliability can
ONLY be achieved when the
equipment is connected to a
receptacle marked "Hospital
Only" or "Hospital Grade".
P/N 034059
Rev D (1) 02/00
WARNING
For proper grounding, junction box MUST
be securely connected to the bed with metal
screws and spacer provided or electrical
shock could occur.
1108103 Rev.A(1) - 08/01
All cable connections MUST be aligned properly. Align locking levers
with locking tabs for proper connection. Mis-alignment of cable
connections will cause permanent product damage.
Locking Lever
Crossover
Cable
Head Motor
Cable
Locking Tab
P/N 1171770 Rev A
CAUTION
Serial number
label located here.
Power Cord
To Next Page
