Standard Quick Clip-On Bed Rails
6627
This item was discontinued 2/16/96
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1027096 Plug Button, Grey (7/8") 1 41
19000X023 Spring, Plunger (23/64 x 5/8") 1 42
1012658-NLA NLA - Spacer, Tube 1 23
1012660 Pin, Plunger 1 44
1012656 Knob, Plunger, Grey 1 45
1012669 Rail, Telescoping - Outside 1 26
1012670 Rail, Telescoping - Inside 1 26
1013305-NLA NLA - Telescoping Rail Assembly 1 27 A
40188X009 Button, Single Snap 1 48
1023490-NLA NLA - Crossbrace Assembly 1 29 B
1022789-NLA NLA - Tube, Channel with Barrel - Left Head End /
Right Foot End
1 210
1022790-NLA NLA - Tube, Channel with Barrel - Left Foot End /
Right Head End
1 210
1022842-NLA NLA - Tube, Channel - Center 1 211
1022652-NLA NLA - Clip, Spring 1 212
A - Includes items 1-6
B - Crossbrace Assembly is no longer available. May be replaced with crossbrace from model 6629.
NOTE:
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048
