Invacare Bed Rails - Parts List for 6628;6628-TSS

Deluxe Spring Loaded Bed Rails
6628 & 6628-TSS
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1121932 Rail, Inside 1 11 F
1121933 Rail, Outside 1 12 F
16347X000 Washer, Nylon (3/16 x 7/16 x 1/8") 1 23
16348X000 Rivet (3/16 x 7/16") 1 24
1057287 Plug Button, Grey (1") 1 85
1122149-NLA NLA - Label, Warning - Reduced Gap 1 16
40314X001-NLA NLA - Ring, Retaining 1 47
40014X020-NLA NLA - Knob, Plunger 1 48
1110764 Clip, Rail - Small 1 29
1110765 Clip, Rail - Large 1 29
1106232 Tube, Channel with Barrel - Inside 1 112
1110951-NLA NLA - Tube, Channel with Barrel, Chrome - Inner
Deluxe
1 112 G
1106234 Tube, Channel with Barrel, Outside 1 113
1110954 Tube, Channel with Barrel, Chrome - Outer Deluxe 1 113
1106235-NLA NLA - Crossbrace Assembly, Chrome 1 214 A,D
1110955 Crossbrace Assembly, Deluxe, Wide 1 214 A,C
16320X007-NLA NLA - Rail, Inside 1 115
16320X006-NLA NLA - Rail, Outside 1 116
1110957 Kit, Bed Rail Hardware 1 1B,E
A - Includes Items 3-12 and the Bed Rail Hardware Kit.
B - Not Shown
C - To be used with a TSS Mattress Only. Crossbraces are extra wide to accommodate the mattress.
D - Both old style and new style models use this crossbrace.
E - Includes the Wing Screws (4) to hold the X-Brace in place on the Bed Frame.
F - 2/1/04 the rails will have 4 rungs instead of 3 so an inner and an outer Rail needs to be ordered when replacing.
G - No longer available as a service part individually. Order item 14 part #1110955 as a replacement.
NOTE:
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048
