Half Length Bed Rails - 6630
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
16364X000-NLA NLA - Half Rail Assembly 1 21 A
1028789 Kit, Frame Bar (Pair) 1 12 B
Bolt, Carriage (1/4-20 x 1-1/4") 1 23
Clamp Bar 1 24
Nut, Wing (1/4-20) 1 25
1007727 Channel Only, Granite 1 26
16357X000 Rail, Top 1 27
16362X000 Rail, Bottom 1 28
16346X000 Bracket, Slide, Chrome 1 29
16363X000 Bushing (4") 1 210
16335X000 Insert 1 211
19000X012 Pin, Plunger 1 212
19000X023 Spring, Plunger (23/64 x 5/8") 1 213
40014X020-NLA NLA - Knob, Plunger 1 114
40314X001-NLA NLA - Ring, Retaining 1 115
16336X000 Bushing, Composite, Nylon (25/32 x 29/32 x 3/4") 1 616
60290X002 Locknut (5/16-18) 1 417 D
16308X000 Washer, Flat (5/16 x 11/16 x 1/16") 1 418 D
16348X000 Rivet (3/16 x 7/16") 1 819
1016386 Instruction Sheet, 6630 Bedrail 1 1C
A - Includes items 7 - 19.
B - Includes items 3 - 5.
C - Not shown in illustration.
D - Used to mount Item 6 to Item 9, mounted to studs already welded to Item 9 on the opposite side from the view in the
illustration. Refer to Instruction Sheet for more detail.
NOTE:
22
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048
